STEP 1
A. Tap/insert ONE 1 1/2” pin into each end of all the doors. DON’T OVERDRIVE PINS! Pins should
stick up about 1/2” when seated.
STEP 2
Take the 2 front braces and tap/insert one 3/4”
steel pin into each end of both braces until seated.
About 3/8” will stick out when seated. Ok if loose.
4 used in this step
3/4” Long 3/16” DIA. Steel Pin
STEP 3
Assembly Spice Rack
Insert retainer
rods into holes
Fasten Shelves with
1 1/4” Phillips Flat Head
#8 Screw (Bronze)
Pilot holes in shelves
go toward back
B. Attach the
magnet plate
(may be stuck
to magnet!) with
the 1/2” #4 screw
to the top of the
doors. Bumps go
toward the wood.
C. Attach door
handles with 7/8”
truss head machine
screws.
