Page 105

- 105 -
Appendix A – Specifications
System
O.S.
Embedded Linux 2.6
Multiplex
Sixfold operation - simultaneous record, live,
playback, backup, control, & remote access
Certification
FCC, CE, LVDS, etc.
Video
Format
NTSC/EIA or PAL/CCIR
Input
16-CH, BNC, 1Vp-p/75ohm
Main monitor
BNC x 1, S-video x 1 (optional), 1Vp-p/75ohm
VGA D-SUB 15-pin connector
Optional HDMI
Support touch panel with USB interface
Call monitor
BNC x 1, 1Vp-p/75ohm
Loss detection
Yes
Motion detection
Yes, with configurable detection area & sensitivity
Privacy mask
Yes
Audio
(optional)
Input
4 RCA-jack connectors, line-in level (100mV-2Vrms)
Output
1 RCA-jack connector, line-out level (up to 2Vrms)
Record
Compression
Video:
H.264
Audio: ADPCM
Frame rate (IPS)
& Resolution
NTSC – 120 / 720*480, 360 / 720*240, 480 / 360*240
PAL – 100 / 720*576, 300 / 720*288, 400 / 360*288
Mode
Manual/Schedule/Alarm/Motion
Pre-record time
0 – 10 seconds
Post-record time
0 - 60 minutes
Display
Resolution
NTSC – 720*480, PAL – 720*576
Split windows
1/4//7/9/10/13/16
Frame rate
Up to 30 (NTSC) / 25 (PAL) IPS per display window
Freeze
Yes
Sequential switch User adjustable
Digital Zoom
X2, X4
Playback
Frame rate (IPS)
& Resolution
NTSC – 60 / 720*480, 120 / 720*240, 240 / 360*240
PAL – 50 / 720*576, 100 / 720*288, 200 / 360*288
Search
Smart search
, Date/time, Camera, Alarm, Motion, &
Video Loss
Operation
Play, Fast Forward, Backward, Pause, Stop, etc.
Remote I.E. and HEM can also Print, Snapshot
Storage
HDD
Up to 3 sets of 3.5” SATA type HDDs,
> 2TB for each HDD,
Advanced format HDD supported
HDD Extension
1 eSATA connector for eSATA HDD
Partitions
Configurable alarm partition size
Configurable auto-overwrite or not
Backup
1 USB 2.0 port for USB 2.0 disk drives, DVD+RW,
DVD+R, DVD-R
, card readers, HDD, etc.
Internal DVD models: DVD+RW, DVD+R, DVD-R
