22
Device Requirements Max. Cord Length (ft) by Wire Gauge
Amps Watts (120V) Watts (240 V) #8 wire #10 wire #12 wire #14 wire #16 wire
2.5 300 600 NR 1000 600 375 250
5 600 1200 NR 500 300 200 125
7.5 900 1800 NR 350 200 125 100
10 1200 2400 NR 250 150 100 50
15 1800 3600 NR 150 100 65 NR
20 2400 4800 175 125 75 50 NR
25 3000 6000 150 100 60 NR NR
30 3600 7200 125 65 NR NR NR
40 4800 9600 90 NR NR NR NR
*NR= not recommended
Figure 18- Maximum Extension Cord Lengths by Power Requirement
DC Usage
This Generator is equipped with a cigarette lighter style 12V DC receptacle. The maximum draw
for this DC outlet is 8.3 Amps. The 12V DC receptacle is not intended for use to charge
automotive batteries.
The cigarette lighter style receptacle permits the use of any electrical device designed for use in a
12V DC cigarette style outlet similar to ones found in automobiles. The electrical device has a
power cord with a metal pin on the bottom and two leaf springs on the sides. Some common
automotive type electrical devices are inflators, vacuum cleaners, chargers of various types and
more.
To Use: Simply plug the electrical device power cord into the 12V DC outlet and ensure the power
cord is securely in place. Use the device as instructed. Remove after use by simply pulling the
power cord out of the receptacle. The 12V DC receptacle is protected against overloads by an in-
line fuse located behind the control panel.
STOPPING THE GENERATOR
To stop the generator:
1. Turn off all electrical devices prior to unplugging them from the generator. Unplugging
running devices can cause damage to the generator.
2. Turn the engine switch to the “OFF”
position.
3. Turn the fuel valve to the “OFF” (horizontal) position.
WARNING: Allow the generator to cool for several minutes before touching
areas that become hot during use.
CAUTION: Allowing gasoline to sit in the generator tank for long periods of time without
use can make it difficult to start the generator in the future. Never store generator for
extended periods of time with fuel in the tank.
