Little Board/P5x Technical Manual
2–45
Table 2– 35 gives the signal pinout of J5 and pin connections for a DB-15 connector. Table 2– 40
shows J5 mating connectors.
Table 2– 35. CRT Interface Connector (J5)
Pin Signal Name DB-15
1 Red 1
2 Ground 6
3 Green 2
4 Ground 7
5 Blue 3
6 Ground 8
7 Horizontal Sync. 13
8 Ground 10
9 Vertical Sync. 14
10 +5V Power -
Table 2– 40. J5 Mating Connectors
Connector Type Mating Connector
RIBBON 3M 3473-7600
Latching Clip 3505-8010
DISCRETE WIRE MOLEX HOUSING 22-55-2102
PIN 16-02-0103
ZV Port Interface (J6)
This section describes the ZV port interface (J6). The ZV port is a PCMCIA standard for video
input. The ZV port can be used to receive video data in either RGB or YUV format. The input data
can be scaled, positioned, and can overlay the Little Board/P5x’s VGA data stream. It can use color
keying for non-rectangular windowing, or X-Y window keying.
For further information about the ZV port and its uses, read application notes for the 69000 video
controller, available at the Intel Website, http://www.intel.com.
