- 22 -
Ref# Description Qty Ref# Description Qty
75 Bolt M6x20 6 88
Hexagon Thin Slotted and
Castle Nuts M20x1.5
2
76 Lock Washer Ø6 6 89 Adjustable Washer
77 Flat Washer Ø6 6 90 Bolt M8x30 4
78 Clamp 2 91 Nut 1
79 Screw M6x10 1 92 Valve B Joiner 1
80 Semicircular Key 1 93 O Ring Ø20x2.4 1
81 Flat Key 5x25 1 94 Front Cover Connector 1
82 Screw ZG1” 1 95 Block 4
83 Hand wheel 1 96 Hex Nut M12x1.25 8
84 M20x1.5 Oil Leveler 1 97 Protecting Tube 2
85 Oil Plug 1 98 Oil Pipe Protecting B 1
86 Seal Belt 8 99 Hex Bolt M5X10 4
87 Oil Pipe Protecting A 1 100 Connector guard 1
Parts Drawing & Parts List
