4212 WENPRODUCTS.COM 9
Assembly and adjustments
Unpacking
Unpack the drill press and all its parts, and compare against the list below. Do not discard the carton or
any packaging until the drill press is completely assembled.
To protect the drill press from moisture, a protective coating has been applied to the machined surfaces.
Remove this coating with a soft cloth moistened with kerosene or WD-40
® . Do not use acetone, gasoline, or
lacquer thinner to clean. Apply a coat of good paste wax to the table and column. Wipe all parts with a clean
dry cloth.
Head/motor assembly
Column assembly and table bracket
Table
Worm shaft
Base
Chuck arbor
Chuck and key
Table lock handles
Hex head bolts (4)
Table crank handle
Hex keys (2)
Feed and speed handles (4)
AA batteries (2)
