USGlobalsat DG-200 Ver.1.1 - Manual (Page 4)

4
Specifications
Electronics
GPS Chipset SiRF StarIII
GPS Antenna Built-in GPS antenna
Operation Time Up to 20 hours
Charging Time 3 hours
Charging port Mini USB port @350mA
Power Button Function
Turn on/ turn off Press and hold for 3 seconds to turn on/ turn off
Save Under power-on status, short click to save the GPS location data
LED
GPS Status (Green)
On : no GPS fix
Flash : GPS fixed
Memory Status
(Blue)
On : Memory is full
Keep flashing : Memory used up to 80%
Flash once : Saved the manually recorded point
Power Status (Red) On : Power low
Charging Status
(Orange) On : Charging (Turn to be off after fully charged)
Temperature
Operation
Temperature -20°C to 60°C
0°C to 45°C while charging
Storage
Temperature -20°C to 70°C
Humidity 5% to 95% non-condensing
Battery
Battery Capacity Li-Ion battery 700mA
MECHANISM
Size 70mm x 40mm x 9mm (2.7” x 1.5” x 0.4”)
Weight 36 g
Certification
FCC USA (Covers requirements for CANADA ICES-003)
CE Europe
BSMI Taiwan
