REPLENISH CASSETTE(S) - NMD-100
STEP ACTION STEP ACTION
G
RASP NOTE CASSETTE
HANDLE WITH ONE HAND
WHILE HOLDING THE MECHA
-
NISM WITH THE OTHER
. P
ULL
THE CASSETTE OUT
SLIGHTLY
,
THEN PLACE ONE
HAND UNDERNEATH AS YOU
SLIDE IT OUT
.
P
LACE CASSETTE ON A LEVEL SURFACE
. I
NSERT KEY
INTO THE CASSETTE LOCK AND TURN CLOCKWISE
. P
RESS
G
REEN RELEASE BUTTON TO RAISE LID
.
M
OVE PUSHER PLATE TOWARDS THE CASSETTE HANDLE
.
P
LATE SHOULD STAY INPLACE
. L
OAD NOTES USING
1" -
2"
STACKS OF CURRENCY
.
L
EVEL NOTE PILE BY HAND
. M
OVE PUSHER PLATE
AGAINST THE NOTES WITH ENOUGH PRESSURE TO HOLD
NOTES BEFORE CLOSING
.
E
XTEND
“P
AWLS
”
FULLY
(I
N
-
SERT
)
ON THE PUSHER PLATE
.
C
LOSE CASSETTE LID TO ITS
LOCKED POSITION
. T
HE
G
REEN RELEASE BUTTON
SHOULD
“P
OP
”
OUT
. T
URN
KEY COUNTERCLOCKWISE TO
LOCK CASSETTE
. S
LIDE CAS
-
SETTE INTO ITS SLOT IN THE
MECHANISM
.
R
EMOVE REJECT CASSETTE FROM MECHANISM
. P
LACE
ON LEVEL SURFACE
. I
NSERT KEY INTO LOCK AND TURN
CLOCKWISE
. P
RESS
G
REEN RELEASE BUTTON TO RAISE
LID
.
R
EMOVE ANY REJECTED NOTES
-
BOTH SINGLE AND
BUNDLED AREAS
. F
OLLOW LOCKING PROCEDURES FROM
S
TEP
6
AND SLIDE CASSETTE BACK INTO MECHANISM
.
Single Note Reject
Area
Bundled Note Reject
Area
