POTS24
| AT-TN113-A 24 Port POTS Service Module
USA Headquarters
|
19800 North Creek Parkway
|
Suite 200
|
Bothell
|
WA 98011
|
USA
|
T: +1 800 424 4284
|
F: +1 425 481 3895
European Headquarters
|
Via Motta 24
|
6830 Chiasso
|
Switzerland
|
T: +41 91 69769.00
|
F: +41 91 69769.11
Asia-Pacific Headquarters
|
11 Tai Seng Link
|
Singapore
|
534182
|
T: +65 6383 3832
|
F: +65 6383 3830
www.alliedtelesis.com
Ordering Information
**Where YY
= 005 for 5 ft
= 010 for 10 ft
= 015 for 15 ft
= 020 for 20 ft
= 030 for 30 ft
= 040 for 40 ft
= 050 for 50 ft
= 060 for 60 ft
= 070 for 70 ft
= 080 for 80 ft
= 090 for 90 ft
iMAP 9x00 Chassis
Model
Description
Part #
iMAP 9700
17-slot chassis with DC power with faceplates
AT-TN-250GF
iMAP 9700
17-slot chassis with DC power without faceplates
AT-TN-250G
iMAP 9400
7-slot chassis with DC power with faceplates
AT-TN-251GF
iMAP 9400
7-slot chassis with DC power without faceplates
AT-TN-251G
MiniMAP 9101
3-slot mini chassis with DC power
AT-TN-9101-A-80
MiniMAP 9102
3-slot mini chassis with AC power
AT-TN-9102-A-XX*
POTS24
Model
Description
Part #
POTS24
24 ports, POTS Service Module
AT-TN-113-A
iMAP Common Control
Model
Description
Part #
CFC24
24GbE switch controller card
AT-TN-401-B
GE3
3x GbE WAN interface card
AT-TN-301-A
CFC12
12GbE switch controller card
AT-TN-408-A
Related iMAP Line Cards and Accessories
Model
Description
Part #
ADSL24
24-port, ADSL2+ Service Module (Annex A)
AT-TN-112-A
CES8
8-port, T1/E1 Circuit Emulation Service Module
AT-TN-119-A
PAC24
24-port, POTS/ADSL2+ Combo w/Splitters, Annex A
AT-TN-123-A
Optimized Splitter Chassis
Splitter Chassis, 3RU, 4 slot (North America only)
AT-TN-S004-A
Optimized Splitter
24-port, Optimized Splitter card (North America only)
AT-TN-S101-A
Optimized Splitter Cable
ADSL24 to High Performance Splitter Cable
AT-TN-C013-A-YY**
Standard Splitter Cable
ADSL24 to Standard Splitter Cable
AT-TN-C018-A-YY**
MDF Kit
Terminal block to RJ-21 Male, 4 cables
AT-TN-K022-A-YY**
CPE Attenuator
ADSL2+ Attenuator
AT-TN-S900-A
Filler
Full size service slot filler plate
AT-TN-M000-A
Interface Specifications
Number of ports:
24
Connector:
RJ-21 (Female)
POTS Specifications
Talk Battery:
48 to 52Volts tip-ring on-hook
Ring Generator:
86-90Vrms, 20Hz into 15REN
2wire impedance:
900 ohms + 2.16uF complex
Frequency Response:
200 – 34000Hz flat
+/- 0.2db
Longitudinal balance:
>45dB
Loop current:
26 – 28mA current limited
Loop range:
0 – 2000 ohms resistance
Loop signaling:
Loopstart supervision,
superimposed ringing
Dialing support:
DTMF, Dial Pulse
VoIP Specifications
CODEC:
G.711, G.726-32k
Packetization:
10, 20, or 30ms
Echo:
G.168 Echo Cancellation
Jitter buffer:
Up to 150ms average delay
with
300ms buffer depth
Power Requirements
Maximum power:
55W
Environmental Conditions
Operating Temp:
-40C to 65C
Storage Temp:
-40C to 75C
Relative Humidity:
5% to 95%, non-condensing
Regulatory Approval
FCC Part 15 Class A/ANSI C63.4
EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A
VCCI Class A; ITE/ CISPR 22:1997 Class A
EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A
EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998
EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996
EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995
EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995
EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999
UL/cUL 60950: IEC60950
NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2
USDA RUS
GR-57-CORE
*Where XX
= 10 for U.S. power cord
= 30 for U.K. power cord
= 40 for Australia power cord
= 50 for Europe power cord
