7
P
USH PACKER PLATE TO
-
WA R D S T H E C A S S E T T E
HANDLE
. P
LATE SHOULD
STAY IN PLACE .
3
1
2
6
P
LACE CASSETTE ON A LEVEL SURFACE
. I
NSERT CAS
-
SETTE KEY INTO THE CASSETTE LOCK AND TURN “ CLOCK -
WISE
”. P
RESS
“G
REEN
”
RELEASE BUTTON TO RAISE LID
.
5 U NLOCK /O PEN DISPENSER SECURITY DOOR . G RASP CAS -
SETTE HANDLE WITH ONE HAND WHILE HOLDING MECHA
-
NISM WITH THE OTHER
. P
ULL CASSETTE OUT SLIGHTLY
,
THEN PLACE ONE HAND UNDERNEATH . R EMOVE CAS -
SETTE
.
STEP ACTION
4
7
C OUNT THE NUMBER OF BILLS THAT REMAIN IN THE CAS -
SETTE
,
IF ANY
.
C OUNT THE NUMBER OF BILLS THAT ARE BEING ADDED
TO THE REMAINING NOTES
.
T
HE
TOTAL
OF THESE AMOUNTS WILL BE ENTERED IN
THE “E NTER C ASSETTE Q UANTITY ” PROMPT FOR C AS -
SETTE
C
LOSE PROCEDURE
.
REPLENISH NMD-100 CASSETTE(S)
8
STEP ACTION
P
LACE CURRENCY IN THE
CASSETTE AND LEVEL NOTE
PILE . M OVE PACKER PLATE
WITH ENOUGH PRESSURE TO
HOLD THE NOTES .
E XTEND THE “P AWLS ” ON PACKER PLATE FULLY . C LOSE
LID AND INSTALL IN DISPENSER
.
C
LOSE CASSETTE LID TO ITS
LOCKED POSITION
. T
HE
G REEN RELEASE BUTTON
SHOULD
“P
OP
”
OUT
. T
URN
KEY “ COUNTERCLOCKWISE ”
TO LOCK CASSETTE
. S
LIDE
CASSETTE INTO ITS SLOT IN
THE MECHANISM
.
R EMOVE THE REJECT CASSETTE . P LACE ON LEVEL SUR -
FACE
. I
NSERT KEY INTO LOCK AND TURN
“
CLOCKWISE
”.
P RESS G REEN RELEASE BUTTON TO RAISE LID .
9 R
EMOVE ANY REJECTED NOTES
-
BOTH SINGLE AND
BUNDLED AREAS . F OLLOW LOCKING PROCEDURES FROM
S
TEP
7
AND SLIDE CASSETTE BACK INTO MECHANISM
.
