Tele Vue NP127is User Manual
Page 6
6
STL-1071 – SBIG STL series camera adapter
• This adapter is sized to thread directly onto the STL series cameras and mates with Imaging System
accessories.
TRG-1072 – Standard T-ring adapter
• This is the most restrictive of adapters as it has the smallest inside diameter. Recommended for use
with APS size or smaller chips.
CWT-2070 – Canon Wide T Adapter
• Adapts Imaging System Accessories to Canon DSLRs. Includes Canon Bayonette mount.
• Eliminates the inner portion of Canon T-rings to provide a larger diameter opening for reduced vignetting.
AD2-1110 – Apogee U47-D2 Camera Adapter
A2A-1107 – 2” Accessory Adapter
• Use for cameras with 2” nosepiece or any other 2” accessory. (Extension tubes may be required to
reach focus.)
• Dual thumb-screws and clamp ring for positive locking.
AFT-1105
–
48mm Filter adapter
• Allows use of 48mm filters in the system.
• Best if used closest to the chip to minimize any vignetting
• Adds 0.25” of spacing.
TLA-0250 – 0.250” (6.4mm) Extension Tube
TLB-0375 – 0.375” (9.5mm) Extension Tube
TLC-0500 – 0.500” (12.7mm) Extension Tube
TLD-1000 – 1.000” (25.4mm) Extension Tube
TLF-0040 – 0.040” (1.0mm) Spacer
TLG-0080 – 0.080” (2.0mm) Spacer
TLS-1121 – Set of TLF-0040 and TLG-0080.
TLS-2245 – Set of all six.
• Threaded coupling provides the necessary distance for proper spacing of field lenses to chip.
Required spacers will vary depending on camera specifications.
• Black anodized aluminum with anti-reflection threads for maximum contrast.
