Technical specifications
Analogue audio inputs
Line input sensitivity
0.5/1/2/4V rms (2V rms normal)
Overload margin +2dB
Input impedance >22kΩ
Analogue audio outputs
Level (at 0dB gain)
2V rms
Maximum level 3.5V rms
Impedance 600Ω
Signal/Noise ratio (analogue input) 100dB unweighted (measurement bandwidth 22kHz)
Signal/Noise ratio (digital input) 100dB unweighted (measurement bandwidth 22kHz)
THD+N (analogue input) 90dB (0.003%) (measurement bandwidth 22kHz)
THD+N (digital input) 90dB (0.003%) (measurement bandwidth 22kHz)
Frequency response 20Hz–20kHz (±0.25dB)
Headphone impedance 390Ω
Video inputs and outputs
Input and output impedance
75Ω
Composite video level 1V
HF response to (-3dB) 12MHz
S-video level (Y/C) 1V/0.28V
HF response to (-3dB) 12MHz
HQ (component) video
level (Y/Cr/Cb) 1V/0.5V/0.5V
level (R/G/B) 1V/1V/1V
HF response to (-3dB) 150MHz
Digital audio inputs
Coaxial connection (level/impedance)
0.5V/75Ω
Acceptable sampling frequencies 44.1kHz, 48kHz and 96kHz
Digital output level/impedance 0.5V/75Ω
Trigger outputs
Output D.C. voltage level
(excl. RGB status) 12V ±1V
Allowable load 30mA max. (min. 400Ω)
Remote inputs and output
Signal modulated 36kHz carrier
Coding Philips RC-5
General
Mains voltage
110V and 230V (switchable)
Power consumption (maximum) 120VA
Dimensions W x D x H (including feet) 430 x 420 x 145mm
Weight (net)
8.3kg
Weight (packed) 13.5kg
Supplied accessories Mains lead, CR80 remote control, 2 x AA batteries
E&OE. All specification values are typical unless otherwise stated.
Continual improvement policy
Arcam has a policy of continual improvement for its products. This means that designs and specifications
are subject to change without notice.
Radio interference
The AVP700 is a digital audio device which have been designed to very high standards of electromagnetic
compatibility.
The unit can radiate RF (radio frequency) energy. In some cases this can cause interference with FM and
AM radio reception. If this is the case, keep the AVP700 player and its connecting cables as far from the
tuner and its aerials as possible. Connecting the AVP700 and the tuner to different mains sockets can
also help to reduce interference.
EU COUNTRIES – These products have been designed to comply with directive 89/336/EEC.
USA – These products comply with FCC requirements.
