Complete Drive Assembly Parts Breakdown
Model # SR-110
Key
Part No.
Description
Qty.
D 6084 Antenna
D
6079
D
5535
D
4135
D
6062
D 6067
D
6122
D
6467
4
6
0
6
D
D
6078
D
6232
D
6715
D
6071
D
6063
D
6750
D
6110
T
15043
A 4005 Complete Drive Assembly
D
6463
D
6398
D
6405
D
6131
#10-32 x 1/2” HHMS W/Washer
1
2
1/2-13 Serrated Flange Nut
4
Hair Pin Clip
1
2 Inch Mounting Tube Weldment
1
Hitch Pin
1
7-Way Spreader Harness
1
#10-32 x 5/8” Serr. Flng.Bolt
2
Plastic Push Pin
4
Motor Cover Enclosure
1
Spinner Motor
1
Motor Drive Coupler
1
Spinner Transmission
1
Switch Assembly
1
Spinner Drive Enclosure
1
Plastic Spinner
1
Material Deflector
1
Plastic Push Pin
2
Spinner Detent Pin
1
Material Agitator
1
1/4-20 x 1/2” Hex Bolt SS
4
D
6061
Wireless Receiver
1
