Page 3
05-23521-0D
Page 3
10' x 10' MAX AP Canopy - 4 Leg - Parts List - Model #23521
Quantity
Part #
Bungee Cords
Description of Parts:
Rafter Poles, Swedge 24 3/8"
4
13104
Poles, Swedge 40 11/16"
14
13103
Cross Poles 40 11/16"
3
13106
3 - Way Frame Connectors
6
13101
1
Canopy Cover
10372
4
Base Feet
10075
12
10066
Leg Poles 39"
4
13105
1. lAYOUt rOOF FrAMe
13106
13106
13106
13103
13103
13103
13103
13103
13103
13101
13101
13101
13101
13103
13103
13104
13104
13104
13104
13103
13103
13101
13101
F
r
ON
t
re
A
r
4
Anchors
10431
