3 x 6,1m supermax, Toldo - lista de partes - modelo – ShelterLogic 23571 10 x 20 Super Max Canopy User Manual
Page 17
Página 17
05-23571-0B
3 x 6,1m SuperMAX
™
Toldo - Lista de Partes - Modelo
nº
23571
Cantidad
Pieza #
Cuerdas Bungee
Descripción of Piezas:
Tubos-vigas, Swedged 54
3
/
4
in. / 139 cm
Postes verticales, Swedged 76 in. / 193 cm
Base de las Patas
Contactos/Anillos Cortos
Contactos/Anillos Largos
TwistTite™
(Cuerda + 'S'-ganchos)
Conectores de estructura de 4 extremos
(Codo Moderato)
Conectores de estructura de 3 extremos
(Codo Moderato)
Conectores de estructura de 4 extremos
(Codo Agudo)
Conectores de estructura de 3 extremos
(Codo Agudo)
Anclas
Cubierta de Toldo
Postes Transversales 77 in. / 195,6 cm
8
8
8
4
8
24
4
2
2
4
4
8
1
9
10091
10043
10050
10066
10056
10051
10052
10046
10048
10045
10047
10431
10302
10044
