3. The case at a glance
Front view (Value and Economy edition)
A
A
B
B
C
D
A
B
C
D
E
F
G
H
I
G
A – 3.5" front bezel
B – 5.25" front bezel
C – Power LED
D – On/Off button
E – HDD LED
F – Reset button
G – USB hub
H – Headphone and microphone connector
I – covered: fan bracket (1x 140 mm fan / Value edition: pre-installed)
Side view
left (Value edition) open (Value and Economy edition)
A – 250 mm fan (pre-installed)
B – Fan brackets (2x 80 mm fans)
A – Mounting bay for 3.5" device
B – Mounting panel for mainboard
C – Mounting bays for 5.25" drives (CD/DVD)
D – HDD cages
