SHARKOON Rebel12 Economy - Manual (Page 10)

REBEL12 REBEL12
ENGLISH
23
250 mm Fan Optical drives
Front fan HDDs
PSU
Fan
The 250 mm fan of the Value edition can be connected to the PSU using the 4-pin
connector. The fan will run at a constant speed.
Alternatively the 250 mm fan can be connected directly to a 3-pin fan connector at the
mainboard. The fan can then be controlled by the mainboard. The 250 mm fan
requires a current of 0.3 A; make sure that your mainboard’s fan connectors can
provide this current.
9. Installation of a 3.5" device (e.g. Floppy)
1. Remove the 3.5" front bezel of the topmost mounting bay.
2. Slide the drive into the mounting bay from the front.
A
B
A – 3.5" device
B – Topmost mounting bay with 3.5" front bezel (removable)
3. Screw the drive to the mounting bay.
