6. Troubleshooting
In case the power supply does not work properly, check the following topics:
1. Is the power cord correctly connected to a wall outlet and the PSU’s power connector?
2. Make sure the on/off switch is turned to the “I” position.
3. Check if the main power connector is correctly plugged to the mainboard.
4. Check if the power connectors are properly connected to the peripheral devices in
case the short circuit protection function was activated when switching on the PSU.
5. Turn the power supply off and back on after at least 5 seconds. Repeat this procedure
several times.
6. In case the PSU still does not start, contact [email protected].
7. Cable diagrams and pin assignments
20+4-pin ATX power connector (mainboard)
4+4-pin P8 power connector
6/6+2-pin PCIe power connector
BLACK
GREEN
ORANGE
BLUE
RED
BLACK
BLACK
BLACK
RED
BLACK
RED +5V
+5V
GND
+5V
GND
GND
-5V
GND
GND
+3.3V
-12V
PS-ON
+12V1 YELLOW
YELLOW
ORANGE
+12V1
+3.3V
GREY
BLACK
RED
BLACK
BLACK
RED
ORANGE
ORANGE
NC
+5V
PW-OK
+5Vsb
+5V
GND
GND
PURPLE
GND
+3.3V
+3.3V
BLACK GND
BLACK GND
BLACK GND
+12V1
+12V1 YELLOW
YELLOW
BLACK GND
+12V2 YELLOW/BLACK
+12V2 YELLOW/BLACK
BLACK GND
YELLOW +12V1
YELLOW +12V1
YELLOW +12V1
BLACK GND
BLACK GND
6PIN
YELLOW +12V1
YELLOW +12V1
YELLOW +12V1
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
RUSH POWER M
