3. In case your PCIe graphics card is equipped with an additional power connector, also
plug the 6-pin (fig. 3a) or 6+2-pin (fig. 3b) PCIe power connector which will provide
a stable power support for your graphics card.
fig. 3a fig. 3b
5.2.3 Connecting optical drives and other peripheral devices
1. Connect the 4-pin plug (fig. 4), the SATA plug (fig. 5) and the 4-pin floppy plug (fig. 6)
to the respective peripheral devices.
fig. 4 fig. 5 fig. 6
Note:
For more information refer to the respective manuals of your drives and peripheral devices.
5.2.4 Connecting the cables to the PSU
Finally connect the modular cables to the PSU according to the connector coding (see
above 4.).
5.2.5 Checking all connections
Make sure that all devices are connected properly then plug the PSU’s power cord to
a wall outlet and switch the power supply on. This ends the installation of the PSU.
