MS140


Fig. 1

1. Unscrew the thumb screws on the back side of the case and remove both side panels.

2. Unscrew the three attachment screws of the HDD mounting panel and remove the panel from the case
(fig. 2 a-c).

Fig. 2 a-c

5. Removing the HDD mounting plate

In order to install long VGA cards, and to utilize the bottom HDD attachment, the left HDD mounting panel
(fig. 1) must be removed as follows:

8
