Installation of an add-on card – SHARKOON MS140 User Manual
Page 17
MS140
4. Slide the 3.5" device into the 3.5" mounting bay and attach it from both sides (fig. 17).
(Screws for 5.25" drive mounting)
Fig. 17
5. Connect the 3.5" device to the power supply and the mainboard.
11. Installation of an add-on card
1. Remove the anchor screw of the slot bezel and take it from the case (fig. 18).
Fig. 18
17
