SHARKOON MS140 User Manual
Page 18
MS140
2. Insert the add-on card into the respective slot of the mainboard and attach it to the case using the
anchor screw (fig. 19).
Fig. 19
12. Installation of additional fans / optimized airflow
1. Place the fan against the respective bracket from the inside of the case.
2. Screw the fan to the attachment from the outside.
Notes:
1. When installing fans, make sure that (cool) air is taken in on the front/bottom of the case and blown
out on its rear side/top. The PC components with the highest heat development should be placed directly
within the airflow.
2. The installation of the lower fan is an additional application for VGA cooling.
The bottom PCI slot of the mainboard will be occupied when used.
18
