52 •
NOTE
"∅
of paper roll" is derived from the internal
diameter of the roll and the thickness of the
residual paper. The residual paper can be
recognized by its pink colour.
4. Close the paper compartment cover.
Insert paper roll
Proceed as outlined below to insert paper in the printer.
CAUTION!
Burns and cuts
− Do not touch the print head. This is very hot
immediately after printing.
− Do not touch the paper cutter.
− Do not hold the paper by the edges. These
too can cause cuts.
1. Open the paper compartment cover.
2. Insert the paper roll.
NOTE
Ensure that the paper roll is correctly aligned.
See adjacent illustration.
3. Close the paper compartment cover until you hear
it engage.
The device is operational.
Position
∅
of paper roll
1
22 mm
2
24 mm
3
27 mm
4
No function
5
No function
6
No function
1 2
3
4
5
6
Internal diameter
of paper roll
Residual
paper
thickness
Ø of paper
roll
