Alto-Shaam 1000-BQ2/128 User Manual
Page 18
1000-BQ2
series
operation
&
care
manual
• 16
MODEL >
1000-BQ2/96
1000-BQ2/128
1000-BQ2/192
ITEM
DESCRIPTION
PART NO.
QTY
PART NO.
QTY
PART NO.
QTY
1
SHELF SLIDE
1061
8
1061
8
1061
16
2*
SHELF CLIP
11533
4
11533
4
11533
8
3
BRACKET, SENSOR MTG .
1008272
1
1008272
1
1008272
2
4
SIDE PANEL
1012106
2
1012106
2
1012106
2
5
CASING BACK
1012107
1
1012145
1
1012107
1
6*
FRAME BRACKET
—
—
—
—
1012120
2
7
BACK PANEL
—
—
—
—
1012121
1
8
TOP COVER
1012109
1
1012144
1
1012122
1
9
TOP CLIP SUPPORT
1012308
5
1012308
5
1012308
10
10
BOTTOM CLIP SUPPORT
1012309
5
1012309
5
1012309
10
11
BOTTOM PANEL SPOT ASSB
5013362
1
5013461
1
5013362
1
12
FRONT TRIM ASSEMBLY
5013358
1
5013403
1
5013358
2
13
DOOR ASSEMBLY
5013417
1
5013417
1
5013417
2
14
SENSOR MOUNTING BLOCK
BK-27878
1
BK-27878
1
BK-27878
2
15*
T-BLOCK
BK-3019
1
BK-3019
1
BK-3019
1
16
BUMPER, PERIMETER, RUBBER
BM-24766
11
BM-24766
12
BM-24766
16
17
REAR BUMPER HALF
—
—
—
—
BM-27494
1
18
FRONT BUMPER
—
—
—
—
BM-27495
1
19*
BUMPER, ALUMINUM FRAME
BM-28029
1
BM-28030
1
—
—
20*
BUSHING, STRAIGHT, STRAIN RELIEF
BU-3964
1
BU-3964
1
BU-3964
1
21
CONTROL
CC-34970
1
CC-34970
1
CC-34970
2
22
CORDSET, 14/3, 15 AMP, 120V
CD-3232
1
CD-3397
1
—
—
CORDSET, 230V
CD-3922
1
CD-3922
1
CD-3922
1
CORDSET, 208-240V
CD-3551
1
CD-3551
1
CD-3551
1
23*
CONNECTOR, #14 FERRULE
CR-34829
3
CR-34829
3
CR-34829
3
24
6" (152mm) RIGID CASTER
CS-2042
2
CS-2042
2
CS-2042
2
25
6" (152mm) CASTER, SWIVEL, PLATE
CS-2231
2
CS-2231
2
CS-2231
4
26
HANGER 6-1/2" ROPE CLEAT 7/16 BLACK NYLON
E2097HR
2
E2097HR
2
E2097HR
2
27
HANDLE, OFFSET MAG LATCH
HD-2566
1
HD-2566
1
HD-2566
2
28
HANDLE, TRANSPORT
HD-26792
1
HD-26792
1
HD-26792
4
29
HINGE, 1-3/8" OFFSET, PAIR, CHROME
HG-22338
1
HG-22338
1
HG-22338
2
30*
10-32 THREADED INSERT
HG-22672
4
HG-22672
4
HG-22672
4
31
NUT, 6-32 HEX, S/S
NU-2361
4
NU-2361
4
NU-2361
8
32
PANEL, OVERLAY, SIMPLE CONTROL BQ
PE-29511
1
PE-29511
1
PE-29511
2
33
PROBE
PR-34494
1
PR-34494
1
PR-34494
2
34*
RIVET, BLIND, #44, STNLS
RI-2100
28
RI-2100
28
RI-2100
68
35
SCREW, 10-32 X 3/4, NF PHIL, FLAT M/S, #18-8 S/S
SC-2072
6
SC-2072
6
SC-2072
12
36
SCREW, 10-32X1-1/2, NF,PHIL, FLAT M/S, 18-8 S/S
SC-2073
14
SC-2073
14
SC-2073
24
37*
10-32 X 1/4" PAN HD GROUND SCREW
SC-2190
1
SC-2190
1
SC-2190
1
38
SCREW, HEX HEAD, 5/16-18 X 1" LONG
SC-2191
4
SC-2191
4
SC-2191
8
39
1/4-20 X 3/4" SHCS PCN
SC-22339
8
SC-22339
8
SC-22339
8
40
SCREW, 6-32 X 1/2", NC PHIL, FLAT,
SC-2239
2
SC-2239
2
SC-2239
4
41
5/16-18 X 5/8" SERR . HEX HD SCREW
SC-2351
16
SC-2351
16
SC-2351
28
42*
6-32 X 1 1/4" ROUND HD
SC-2365
2
SC-2365
2
SC-2365
2
43*
8-32 X 1/4" PHIL SCREW
SC-2459
29
SC-2459
29
SC-2459
31
44*
1/4-20 X 3/4" FLANGED HD
SC-25286
2
SC-25286
2
SC-25286
2
45*
SCREW, 10-32 X1/2, NF PHIL TRUSS M/S, 18-8 SS
—
—
—
—
SC-2661
12
46
SHELF, NICKEL CHROME
SH-2835
4
SH-22727
4
SH-2835
8
47
SPACER, SNAP-IN, 7/16"
SP-29392
6
SP-29392
6
SP-29392
12
48
SWITCH, ROCKER, 125-277V, 20A
SW-34769
1
SW-34769
1
SW-34769
2
49
WASHER, 6-32, FLAT, NYL
WS-23148
4
WS-23148
4
WS-23148
8
50*
5/16" FLAT WASHER
WS-23725
6
WS-23725
6
WS-23725
10
51*
STAR LOCK WASHER
WS-2467
1
WS-2467
1
WS-2467
1
S E R V I C E
S E R V I C E P A R T S L I S T
*
not
shown
