SANDPIPER EB2-SM - Manual (Page 7)

520-097-000 8/00 MODEL EB2-SM PAGE 7
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD. Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most War-
ren Rupp distributors. The pump owner
may prefer to maintain a limited inventory
of these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
000…Assembly sub assembly;
and some purchased items
010…Cast Iron
015…Ductile Iron
025…Music Wire
080…Carbon Steel AISI B-1112
100…Alloy 20
110…Alloy Type 316 Stainless Steel
111…Alloy Type 316 Stainless Steel (Electro Polished)
112…Alloy “C”
113…Alloy Type 316 Stainless Steel (Hand Polished)
114…303 Stainless Steel
115…301/302/304 Stainless Steel
120…416 Stainless Steel (Wrought Martensitic)
148…Hardcoat Anodized Aluminum
150…6061-T6 Aluminum
151…6063-T6 Aluminum
154…Almag 35 Aluminum
155 or 156…356-T6 Aluminum
157…Die Cast Aluminum Alloy #380
159…Anodized Aluminum
162…Brass Yellow Screw Machine Stock
170…Bronze Bearing Type Oil Impregnated
180…Copper Alloy
330…Plated Steel
331…Chrome Plated Steel
332…Electroless Nickel Plated
335…Galvanized Steel
355…Thermoplastic Elastomer
356…Hytrel
357…Rupplon (Urethane Rubber)
358…Rupplon (UrethaneRubber) Colorcoded: PURPLE
(Some Applications,CompressionMold)
360…Buna-N Rubber Color coded: RED
363…Viton (Fluorel) Color coded: YELLOW
364…E.P.D.M Rubber Color coded: BLUE
365…Neoprene Rubber Color coded: GREEN
366…Food Grade Nitrile Color coded: WHITE
368…Food Grade EPDM
375…Fluorinated Nitrile
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
500…Delrin 500
501…Delrin 570
520…Injection Molded PVDF Natural Color
541…Nylon, glass filled
542…Nylon, unfilled
544…Nylon Injection Molded
550…Polypropylene
551…Polypropylene, glass filled
552…Polypropylene, unfilled
555…PVC (Polyvinyl Chloride)
580…Ryton
600…Teflon (virgin material) Tetrafluoroethylene (TFE)
603…Blue Gylon
604…Teflon – Diaphragm
606…Teflon
610…Teflon Encapsulated Silicon
611…Teflon Encapsulated Viton
Delrin, Teflon, Hytrel and Viton are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock Inc.
Warren Rupp, Rupplon, and SandPIPER are registered
tradenames of Warren Rupp, Inc.
Ryton is a registered tradename of Phillips Chemical
Company.
MATERIAL CODES
The Last 3 Digits of Part Number
32 545-007-330 Nut, Hex 8
33 196-088-010 Outer Chamber 2
34 722-055-012 Valve Seat 4
35 560-079-611 O-Ring 4
560-079-360 O-Ring 4
36 050-005-360 Check Valve, Ball 4
050-005-354 Check Valve, Ball 4
050-005-365 Check Valve, Ball 4
050-010-600 Check Valve, Ball 4
37 560-008-611 O-Ring 4
560-008-360 O-Ring 4
38 670-037-010 Ball Retainer 4
39 900-003-330 Lockwasher 8
40 171-040-330 Capscrew 8
41 326-031-080 Mounting Foot 2
42 286-020-604 Overlay Diaphragm 2
43 518-110-010 Suction Side Only For Filter Press 2
44 560-012-611 O-Ring 4
560-012-360 O-Ring 4
45 170-081-330 Capscrew, Hex Head 4
46 132-022-360 Bumper 2
47 170-060-330 Capscrew, Hex Head 8
48 170-035-330 Capscrew, Hex Head 8
ITEMS NOT SHOWN:
031-019-156 Valve Body Assembly 1
(consisting of Items 9, 10, 11, 13, 14, 15, 16)
031-019-010
Valve Body Assembly 1
(consisting of Items 9, 10, 11, 13, 14, 15, 16)
535-037-000
Caution Plate 4
NOTE: To make suction side in-line serviceable, order Free Standing Base
Kit 475-129-000.
