Model PB½ -A Type 3 Page 6 520-041-000 2/99
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD. Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce re-
pair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
31 560-071-611 O-Ring 4
560-071-360 O-Ring 4
32 722-046-110 Seat 4
722-046-552 Seat 4
722-046-520 Seat 4
722-046-542 Seat 4
722-046-606 Seat 4
722-063-552 Seat 2 4
33 050-022-600 Check Valve Ball 4
050-027-354 Check Valve Ball 4
050-027-356 Check Valve Ball 4
050-027-360 Check Valve Ball (use with seat 4
722-063-552)
050-027-365 Check Valve Ball (use with seat 4
722-063-552)
34 312-042-552 Discharge Elbow 2
312-042-520 Discharge Elbow 2
312-042-542 Discharge Elbow 2
312-042-606 Discharge Elbow 2
35 312-043-552 Suction Elbow 2
312-043-520 Suction Elbow 2
312-043-542 Suction Elbow 2
312-043-606 Suction Elbow 2
36 518-067-552 Manifold 2
518-067-520 Manifold 2
518-067-542 Manifold 2
518-067-606 Manifold 2
37 710-011-115 Self-Tapping Screw 8
38 170-063-115 Hex Head Capscrew 6
170-001-115 Hex Head Capscrew 6
(Teflon Wetted Pumps Only)
39 901-037-115 Washer 12
40 518-101-552 Manifold Dual Port 1/2
(Optional)
Not Shown
535-015-000 Name Plate 1
710-010-115 Self-Tapping Screw 4
031-043-551 Air Valve Body Assembly 1
(Incl. Items 1, 2, 3, 4, 5)
547-002-115 Stop Nut (Used to hold suction and 12
discharge elbow to the outer chambers)
1 Standard production on non-overlay models, but also required on overlay
models if disassembly has occurred for repair.
2 Use only with 050-027-360 or 050-027-365 ball valves.
3 Available as kit only, order 475-130-000. If muffler needs to be piped to
area of safe disposition, order exhaust cap kit 475-107-000.
Continued from previous page
375…Fluorinated Nitrile
378…High density Polypropylene
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…Teflon (virgin material) Tetrafluoroethylene (TFE)
601…Teflon (Bronze and moly filled)
602…Filled Teflon
603…Blue Gylon
604…Teflon
606…Teflon
610…Teflon Encapsulated Silicon
611…Teflon Encapsulated Viton
Delrin, Teflon, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
Rupplon, SandPIPER, PortaPump, Tranquilizer, and
SludgeMaster are registered tradenames of Warren
Rupp Inc.
