SANDPIPER PB3/4-A User Manual
Page 6
Model PB¾
-A Type 3 Page 6
520-121-000 7/99
ITEM
TOTAL
NO.
PART NUMBER
DESCRIPTION
RQD.
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce re-
pair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
34
312-083-552
Discharge Elbow
2
312-083-520
Discharge Elbow
2
35
312-066-552
Suction Elbow
2
312-066-520
Suction Elbow
2
36
518-066-552
Manifold
2
518-066-520
Manifold
2
37
706-018-115
Machine Screw
8
38
170-029-115
Hex Head Capscrew
6
39**
360-074-360
Gasket, Spacer
2
40
560-083-611
O-Ring
4
Not Shown:
031-043-551
Air Valve Body Assy.
1
(Incl. Items 1, 2, 3, 4, 5)
**Standard production on non-overlay models, but also required on
overlay models if disassembly has occurred for repair.
Continued from previous page
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…Teflon (virgin material) Tetrafluoroethylene (TFE)
601…Teflon (Bronze and moly filled)
602…Filled Teflon
603…Blue Gylon
604…Teflon
606…Teflon
610…Teflon Encapsulated Silicon
611…Teflon Encapsulated Viton
Delrin, Teflon, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
Rupplon, SandPIPER, PortaPump, Tranquilizer, and
SludgeMaster are registered tradenames of Warren
Rupp Inc.
