SANDPIPER RHDB2 Metallic - Manual (Page 6)

rhdb2dl1sm-rev0614 Model RHDB2 Page 4
Dimensions: RHDB2 Bottom Ported
Dimensions are ± 1/8"
Figures in parenthesis = millimeters
Dimensions: RHDB2 Top Ported
Dimensions are ± 1/8"
Figures in parenthesis = millimeters
14.93
379
15.50
394
22.63
575
AIR INLET
3/4" FNPT
3.43
87
15.27
388
9.59
243
15.62
397
25.59
650
15.37
390
.18
5
DISCHARGE PORT
2" FNPT
SUCTION PORT
2" FNPT
3/4" NPT EXHAUST
10.50
267
12.50
318
8.63
219
8X .44 [11] MTG. HOLE
SUCTION AND DISCHARGE PORTS ARE
AVAILABLE WITH 2" BSP CONNECTIONS
SUCTION AND DISCHARGE PORTS CAN
BE ROTATED 90 FOR VERTICAL PORTING
15.50
394
5.73
146
22.45
570
1.00
25 AIR INLET
3/4" NPT
9.59
243
15.62
397
25.59
650
15.37
390
9.05
230
20.89
531
.18
5
DISCHARGE PORT
2" NPT
SUCTION PORT
2" NPT
3/4" NPT EXHAUST
8X .44 [11] MTG.HOLE
8.63
219
10.50
267
12.50
318
SUCTION AND DISCHARGE PORTS ARE
AVAILABLE WITH 2" BSP CONNECTIONS
SUCTION AND DISCHARGE PORTS CAN
BE ROTATED 90 FOR VERTICAL PORTING
