dmf3sdl7sm-rev0614 Model DFM3S Page 2
Meanings of
Abbreviations:
A = Compressed Fibre CI = Cast Iron
AL = Aluminum PS = Plated Steel
Alm = Almag 35 Aluminum SS = Stainless Steel
B = Nitrile
Explanation of Pump Nomenclature: DMF3S
II 2GD T5
II 2 G c T5
II 3/2 G c T5
II 2 D c T100oC
All models, including pumps equipped with Aluminum wetted and midsection parts.
See page 16 for ATEX Explanation of Type Examination Certificate.
DMF3S
Type 7
Manifold
Elbow
Outer
Chamber
Inner
Chamber
Outer
Diaphragm
Plates
Inner
Diaphragm
Plate
Intermediate
Housing
Diaphragm
Rod
Valve
Seat
Hardware Diaphragm Flap
Valve
Material
Seat
Gasket
Sealing
Rings
Shippping
Wt. (lbs)
DB-7 356-T6AL 356-T6AL 356-T6AL Alm35AL Alm35AL 356-T6AL 416SS SS PS B B A B 245
MATERIALS OF CONSTRUCTION
To order a pump or replacement parts, first enter the Model Number DMF3S, followed by the Type Designation listed below in the far left column.
Materials
Operating Temperatures
For specific applications, always consult “Chemical Resistance Chart" Technical Bulletin
Nitrile General purpose, oil-resistant. Shows good solvent, oil, water and hydraulic fluid resistance. Should
not be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro
hydrocarbons.
Maximum Minimum
190°F -10°F
88°C -23°C
Maximum and Minimum Temperatures are the limits for which
these materials can be operated. Temperatures coupled with
pressure affect the longevity of diaphragm pump components.
Maximum life should not be expected at the extreme limits of
the temperature ranges.
