dmf3sdl7sm-rev0614 Model DFM3S Page 12
ITEM
NO. PART NUMBER DESCRIPTION QTY.
35 545.007.330 NUT, HEX - 7/16-14 20
36 545.008.330 NUT, HEX, 1/2-13 32
37 547.002.110 NUT, STOP 8
38 547.006.330 NUT, STOP 2
39 560.001.360 O-RING 2
40 560.020.360 O-RING 6
41 560.022.360 O-RING 2
42 570.002.360 PAD, HINGE 4
43 570.012.371 PAD, WEAR 2
44 612.014.000 PLATE, DIAPHRAGM 2
45 612.015.156 PLATE, OUTER DIAPHRAGM 2
46 618.003.330 PLUG, PIPE, 1/4 2
47 618.004.330 PIPE, PLUG 2
48 620.011.114 PLUNGER, ACTUATOR 2
49 670.006.115 RETAINER, FLAP VALVE 4
50 685.008.120 ROD, DIAPHRAGM 1
51 720.004.360 SEAL, U-CUP 2
52 722.007.010 SEAT, FLAP VALVE 4
53 807.016.330 7/16-14 STUD 12
54 807.017.330 7/16-14 X 3 STUD 8
55 807.018.110 STUD, 1/4-20 8
56 900.003.330 WASHER, LOCK, 1/2 16
57 900.006.330 WASHER, LOCK - 7/16 12
58 901.006.330 WASHER, FLAT, 1/2 12
59 901.011.180 WASHER 12
60 901.013.180 WASHER, SEALING 2
61 901.023.330 WASHER, FLAT 2
Model DMF3S Parts List, Continued
