Model T20 Metallic •

8

Composite Repair Parts List

LEGEND:
= Items contained within Air End Kits

= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.

Item

Part Number

Description

Qty

1

031.183.313

Air Valve Assembly (ATEX Compliant)

1

031.179.000

Air Valve Assembly

1

2

050.017.351

Ball, Check

4

050.017.366

Ball, Check

4

050.018.600

Ball, Check

4

3 070.006.170 Bushing

2

4

095.110.000

Pilot Valve Assembly

1

095.110.110

Pilot Valve Assembly

1

5

114.024.313

Intermediate Bracket

1

114.024.110

Intermediate Bracket

1

6

132.035.360

Bumper, Diaphragm

2

7

135.034.506

Bushing, Plunger

2

8

165.116.313

Cap, Air Inlet Assembly

1

165.116.110

Cap, Air Inlet Assembly

1

9

170.052.115

Capscrew, Hex Hd 3/8-16 X 2.25

16

10

170.060.115

Capscrew, Hex Hd 7/16-14 X 2.00

16

11

170.069.115

Capscrew, Hex Hd 5/16-18 X 1.75

4

12

171.053.115

Capscrew, Soc Hd 3/8-16 X 2.50

4

(Stroke Indicator Only)

170.006.115

Capscrew, Hex HD 3/8-16 X 1.00

4

13

171.059.115

Capscrew, Soc Hd 7/16-14 X 1.25

8

14

196.167.110

Chamber, Outer

2

15

196.168.313

Chamber, Inner

2

196.168.110

Chamber, Inner

2

16

286.020.604

Diaphragm, Overlay

2

18 286.007.351 Diaphragm

2

286.007.366 Diaphragm

2

19

360.093.360

Gasket, Air Valve

1

20

360.103.360

Gasket, Pilot Valve

1

21

360.104.379

Gasket, Air Inlet

1

22

360.105.360

Gasket, Inner Chamber

2

Item Part Number

Description

Qty

23

518.145.110TC Manifold, Suction

1

24

518.146.110TC Manifold, Discharge

1

25

545.005.115

Nut, Hex 3/8-16

16

26

545.007.115

Nut, Hex 7/16-14

16

27

560.001.379

O.Ring

2

28

612.192.157 Plate, Inner Diaphragm Assembly

2

29

612.194.110

Plate, Outer Diaphragm Assembly

2

30

612.195.157

Plate, Inner Diaphragm

2

(used with 286.020.604)

31

612.097.110

Plate, Outer Diaphragm Assembly

2

(use with 286.020.604)

32

620.020.115

Plunger, Actuator

2

33

675.042.115

Ring, Retaining 2

34

685.058.120

Rod, Diaphragm

1

35

720.004.360

Seal, Diaphragm Rod

2

36

722.040.110

Seat, Check Ball (seals required see item 28)

4

37

900.005.115

Washer, Lock

16


38

901.038.115

Washer, Flat 5/16

4

39

901.048.115

Washer, Flat 3/8

4

(Sroke Indicator Only)

40

560.079.611

Seal (O.Ring) (See item 34)

8

46

530.033.000

Metal Muffler

1

Parts Not Shown (For Rubber Mounting Feet)

350.001.360

Foot, Rubber

4

170.018.115

Capscrew, Hex Hd

4

545.005.115

Nut, Hex

4

900.005.115

Washer, Lock

4

901.005.115

Washer, Flat

8
