Composite repair parts list – SANDPIPER T1F User Manual
Page 11
t1fmdl1sm-rev0614
sandpiperpump
.
com
Model T1F Metallic •
8
ITEM
PART NUMBER
DESCRIPTION
QTY
1
031.183.313
Air Valve Assembly
1
2
050.028.351
Ball, Check
4
050.028.366
Ball, Check
4
050.028.600
Ball, Check
4
3
070.012.170
Bushing
2
4
095.110.313
Pilot Valve Assembly
1
5
114.025.313
Intermediate
1
6
132.019.360
Bumper
2
7
135.036.506
Bushing
2
8
165.120.313
Cap, Air Inlet Assembly
1
9
170.005.115
Capscrew, Hex Hd 5/16-18 X .88
16
10
170.045.115
Capscrew, Hex Hd 5/16-18 X 1.25
16
11
170.069.115
Capscrew, Hex Hd 5/16-18 X 1.75
4
12
170.006.115
Capscrew, Hex HD 3/8-16 X 100
4
13
196.173.110
Chamber, Outer
2
14
286.008.351
Diaphragm
2
286.008.366
Diaphragm
2
15
286.015.604
Diaphragm, Overlay
2
16
360.093.360
Gasket, Air Valve
1
17
360.103.360
Gasket, Pilot Valve
1
18
360.104.379
Gasket, Air Inlet Cap
1
19
518.175.110TC
Manifold, Suction
1
ITEM
PART NUMBER
DESCRIPTION
QTY
20
518.176.110TC
Manifold, Discharge
1
21
560.001.360
O.Ring
2
22
560.091.611
Seal (Check Valve) (See item 29)
8
23
612.022.330
Plate, Inner Diaphragm
2
24
612.101.110
Plate, Outer Diaphragm Assembly
2
25
620.022.115
Plunger, Actuator
2
26
675.042.115
Ring, Retaining
2
27
685.060.120
Rod, Diaphragm
1
28
720.010.375
Seal, U.Cup
2
29
722.098.110
Seat, Check Ball (seals required see item 22) 4
30
901.038.115
Washer, Flat 5/16
4
31
901.048.115
Washer, Flat 3/8
4
36
530.033.000
Metal Muffler
1
Parts Not Shown (For Rubber Mounting Feet):
171.066.115
Capscrew, Socket Hd
4
350.002.360
Foot, Rubber
4
545.003.115
Nut, Hex
4
900.001.115
Washer, Flat
4
901.035.115
Washer, Lock
4
Composite Repair Parts List
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
3: EXP
VIEW
