• Model G1F Metallic
Explanation of Pump Nomenclature
ATEX Detail
Non-Wetted Material Options
A Painted Aluminum
B Unpainted Aluminum with Stainless Steel Gas Valve
D Unpainted Aluminum with Stainless Steel Gas Valve with FKM O-rings
X Unpainted Aluminum
0 Unpainted Aluminum/FKM Elastomer
V Painted Aluminum/ FKM Elastomer
Porting Options
N NPT Threads
B BSP (Tapered) Threads
R 150# Raised Face 1" ANSI Flange w/ Threaded Pipe Connections
W 150# Welded Raised Face 1" ANSI Flanged Manifolds
Pump Style
S Standard
Muffler Options
X No Muffler Permitted *
Pump Brand
G Natural Gas Operated
Pump Size
1F 1"
Check Valve Type
B Ball
Design Level
1 Design Level
Wetted Material
S Stainless Steel
A Aluminum
Diaphragm/Check Valve Materials
B Nitrile/Nitrile
T PTFE -Nitrile/PTFE
5 Nitrile/PTFE
Check Valve Seat
T Virgin PTFE
A Aluminum
S Stainless Steel
Your Serial #: (fill in from pump nameplate) _____________________________________
Pump Pump Check Design Wetted Diaphragm/ Check Valve Non-Wetted Porting Pump Muffler Pump
Brand Size Valve Level Material Check Valve Seat Material Options Style Options Options
G XX X X X X X X X X X XX Model #:
G __ ____ __ __ __ __ __ __ __ __ __ ____
(fill in from pump
nameplate)
Your Model #:
(1)
II 2GD T5
II 2G c T5
II 3/2 G c T5
II 2D c T100°C †
Models equipped with Wetted Options A or S, Non-Wetted Options A, B, D, X, 0, or V,
Pump Option X.
Note: See ATEX Explanation of Type Examination Certificate
