• Model G1F Metallic
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Gas End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item Part Number Description Qty
1 031-179-000 Stainless Steel Gas Valve Assembly
(use with Option B) 1
031-179-363 Stainless Steel Gas Valve Assembly
with FKM O-rings (used with Option D) 1
031-183-000 Gas Valve Assembly 1
031-183-363 Gas Valve Assembly 1
2 050-028-360 Ball, Check 4
050-028-600 Ball, Check 4
3 070-012-170 Bushing 2
4 095-110-000 Pilot Valve Assembly 1
095-110-363 Pilot Valve Assembly with FKM O-rings 1
5 114-025-157 Intermediate Bracket 1
6 132-019-360 Bumper, Diaphragm 2
132-019-363 Bumper, Diaphragm 2
7 135-036-506 Bushing, Plunger 2
8 165-120-000 Cap, Gas Inlet Assembly 1
9 170-044-330 Capscrew, Hex Hd 5/16-18 X .1.00 16
10 170-045-330 Capscrew, Hex Hd 5/16-18 X 1.25 16
11 170-069-330 Capscrew, Hex Hd 5/16-18 X 1.75 4
12 170-006-330 Capscrew, Hex 3/8-16 X 1.00 4
13 196-173-157 Chamber, Outer 2
196-173-110 Chamber, Outer 2
14 286-008-360 Diaphragm 2
15 286-015-604 Diaphragm, Overlay 2
16 360-093-360 Gasket, Natural Gas Valve 1
17 360-114-360 Gasket, Pilot Valve 1
18 360-104-379 Gasket, Gas Inlet 1
19 518-175-156 Manifold, Suction 1
518-175-156E Manifold, Suction 1"BSP (Tapered) 1
518-175-156W Welded Raised Face 150#
1" ANSI Flanged Manifold 1
518-175-110 Manifold, Suction 1
518-175-110E Manifold, Suction 1"BSP (Tapered) 1
518-175-110W Welded Raised Face 150#
1" ANSI Flanged Manifold 1
20 518-176-156 Manifold, Discharge 1
518-176-156E Manifold, Discharge 1"BSP (Tapered) 1
518-176-156W Welded Raised Face 150#
1" ANSI Flanged Manifold 1
518-176-110 Manifold, Discharge 1
518-176-110E Manifold, Discharge 1"BSP (Tapered) 1
518-176-110W Welded Raised Face 150#
1" ANSI Flanged Manifold 1
Item Part Number Description Qty
21 560-001-363 O-Ring 2
560-001-360 O-Ring 2
22 560-091-360 O-Ring (metallic seats only) 8
560-091-611 O-Ring (metallic seats only) 8
23 612-022-330 Plate, Inner Diaphragm 2
24 612-108-157 Plate, Outer Diaphragm Assembly 2
612-101-110 Plate, Outer Diaphragm Assembly 2
25 620-022-115 Pin, Actuator 2
26 675-042-115 Ring, Retaining 2
27 685-060-120 Rod, Diaphragm 1
28 720-010-363 Seal, U-Cup 2
720-010-375 Seal, U-Cup 2
29 722-098-600 Seat, Check Valve 4
722-098-110 Seat, Check Valve 4
722-098-150 Seat, Check Valve 4
30 900-004-330 Washer, Lock, 5/16 16
31 901-038-330 Flat, Washer 4
32 920-025-000 Ground Strap 1
Parts not shown used with Raised Face ANSI Flange Options R and W:
170.043.330 Hex Cap Screw 4
326.050.080 Mounting Foot 2
545.003.330 Hex Nut 4
900.001.330 Lock Washer 4
901.002.330 Flat Washer 8
Parts not shown used with Raised Face ANSI Flange Option R ONLY:
334.112.110 1" ANSI 150# Raised Face Flange and
Threaded Pipe Connection 2
538.035.110 1" NPT Pipe Nipple x 1 1/2 Long 2
