Page 3
Warren Rupp, Inc. A Unit of IDEX Corporation P.O. Box 1568 Mansfield, Ohio 44901-1568 USA (419) 524-8388 Fax (419) 522-7867 • www.warrenrupp.com
sma3dl1sm-REV0714
Model SMA3-A Page 3
ITEM
TOTAL
NO.
PART NUMBER
DESCRIPTION
RQD.
1
180-002-155
Volute Casing
1
2
258-003-010
Suction Cover
1
3
444-002-010
Impeller
1
4
612-002-080
Wear Plate
1
5
430-008-155
Motor Housing
1
6
775-002-155
Filter Spool
1
7
800-003-330
Strainer Assembly
1
8
430-007-155
Intermediate Housing
1
9
730-009-120
Shaft
1
10
430-010-150
Bearing Housing
1
11
720-002-000
Shaft Seal
1
12
070-002-000
Ball Bearing
1
13
755-001-000
Sleeve
2
14
552-001-000
Oil Seal
1
15
670-004-162
Seal Retainer
1
16
914-002-330
Governor Weight
2
17
590-002-115
Governor Pin
1
18
675-001-115
Retaining Ring
2
19
775-003-162
Governor Spool
1
20
780-002-115
Governor Spring
1
21
670-003-115
Spring Retainer
1
22
255-001-000
Coupling Assembly
1
22-1
770-013-000
Spider Insert
1
23
320-002-000
Filter Element
1
25
770-001-162
Spacer
1
26
525-003-000
Air Motor Assembly
1
Consists of:
26-1
AD-665
Body
1
26-2
AD-666
End Plate, Drive
1
26-3
AD-651
End Plate, Dead
1
26-4
AD-652
Rotor Assembly
1
26-5
AD-691
Vane
4
26-6
AD-692
Spring, Vane
4
26-7
AD-655-A
Push Pin
2
26-8
AD-638-A
Bearing, Drive
1
26-9
AC-437
Bearing, Dead
1
26-10
AC-849
Seal, Shaft
1
26-11
AB-162
Pin, Dowel
5
26-12
AD-641-F
Gasket, End Plate
2
26-13
AD-642-A
End Cap, Dead
1
26-14
AD-643
End Cap, Dead
1
26-15
AD-644
End Cap, Gasket
1
26-16
560-003-360
O-Ring
1
27
530-001-000
Muffler Assembly
1
Consists of:
27-1
560-199-360
O-Ring
2
27-2
538-001-555
Nipple
1
27-3
860-009-150
Tube
1
27-4
165-001-155
Cap, Upper
1
27-5
165-002-155
Cap, Lower
1
27-6
685-001-080
Rod
1
27-7
546-002-115
Cap Nut
1
27-8
901-024-180
Sealing Washer
2
Repair Parts shown in
bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most War-
ren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock to
reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some
purchased items
010... Cast Iron
015... Ductile Iron
080... Carbon Steel, AISI B-1112
100... Alloy 10
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 302/304 Stainless Steel
117... 440-C Stainless Steel (Martensitic)
120... 416 Stainless Steel (Wrought Martensitic)
123... 410 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
149... 2024-T4 Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
152... 2024-T4 Aluminum (2023-T351)
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
165... Cast Bronze, 85-5-5-5
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
310... PVDF Coated
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D + /-5. Color coded: RED
357... Rupplon (Urethane Rubber)
Color coded: PURPLE (Injection mold)
358... Rupplon (Urethane Rubber)
Color coded: PURPLE (Some Applications)
(Compression Mold)
360... Nitrile Rubber. Color coded: RED
363... FKM (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Neoprene. Color coded: WHITE
370... Butyl Rubber. Color coded: BROWN
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
465... Fibre
500... Delrin 500
505... Acrylic Resin Plastic
540... Nylon
550... Polyethylene
555... PVC
570... Rulon II
580... Ryton
590... Valox
591... Nylatron G-S
592... Nylatron NSB
600... PTFE (virgin material) Tetrafluoracarbon (TFE)
601... PTFE (Bronze and moly filled)
602... Filled PTFE
603... Blue Gylon
604... PTFE — Diaphragm
SERVICE AND OPERATING MANUAL
Model SLUDGEMASTER
®
SMA3-
A
