Dual port option drawing – SANDPIPER S07 User Manual
Page 29
s07nmdl1sm-rev0614
Models S07 Non-Metallic Page 27
Dual Port Option Drawing
¾" NPT or ¾" BSPT
Connection
1½" NPT or 1½" BSPT External
¾" NPT or ¾" BSPT Internal
Connections
Illustration for Single Port Suction with
Dual Port Discharge
¾" NPT or ¾" BSPT
Connection
¾" NPT or ¾" BSPT
Connection
1½" NPT or 1½" BSPT (External)
¾" NPT or ¾" BSPT (Internal)
Connections
Illustration for Dual Port Suction and Single
or Dual Port Discharge
