SANDPIPER S20 Metallic - Manual (Page 12)

s20mdl1sm-rev0614
sandpiperpump
.
com
9
• Model S20 Metallic
518.145.110E Manifold, Suction 2" BSP Tapered 1
518.145.110W Welded Raised Face 150#
2" ANSI Flanged Manifold 1
Item Part Number Description Qty
24 518.146.156 Manifold, Discharge 1
518.146.156E Manifold, Discharge 2" BSP Tapered 1
518.146.156W Welded Raised Face 150#
2" ANSI Flanged Manifold 1
518.146.010 Manifold, Discharge 1
518.146.010E Manifold, Discharge 2" BSP Tapered 1
518.146.110 Manifold, Discharge 1
518.146.110E Manifold, Discharge 2" BSP Tapered 1
518.146.110W Welded Raised Face 150#
2" ANSI Flanged Manifold 1
25 545.005.115 Nut, Hex 3/8-16 16
545.005.330 Nut, Hex 3/8-16 16
26 545.007.115 Nut, Hex 7/16-14 16
545.007.330 Nut, Hex 7/16-14 16
27 560.001.360 O.Ring 2
28 612.192.157 Plate, Inner Diaphragm 2
612.192.010 Plate, Inner Diaphragm 2
612.214.150 Plate, Inner Diaphragm
(use with one.piece bonded diaphragm 286.118.000) 2
29 612.194.157 Plate, Outer Diaphragm Assembly 2
612.194.010 Plate, Outer Diaphragm Assembly 2
612.194.110 Plate, Outer Diaphragm Assembly 2
30 612.195.157 Plate, Inner Diaphragm (used with 286.020.604) 2
612.195.010 Plate, Inner Diaphragm (used with 286.020.604) 2
31 612.039.010 Plate, Outer Diaphragm Assembly
(used with 286.020.604) 2
612.097.110 Plate, Outer Diaphragm Assembly
(used with 286.020.604) 2
612.039.157 Plate, Outer Diaphragm Assembly
(used with 286.020.604) 2
32 620.020.115 Plunger, Actuator 2
33 675.042.115 Ring, Retaining 2
34 685.058.120 Rod, Diaphragm 1
35 720.004.360 Seal, Diaphragm Rod 2
36 722.040.550 Seat, Check Ball 4
722.040.360 Seat, Check Ball 4
722.040.363 Seat, Check Ball 4
722.040.364 Seat, Check Ball 4
722.040.365 Seat, Check Ball 4
722.040.080 Seat, Check Ball (seals required see item 40) 4
722.040.110 Seat, Check Ball (seals required see item 40) 4
722.040.150 Seat, Check Ball (seals required see item 40) 4
722.040.600 Seat, Check Ball 4
37 900.005.115 Washer, Lock 16
900.005.330 Washer, Lock 16
38 901.038.115 Washer, Flat 5/16 4
901.038.330 Washer, Flat 5/16 4
39 901.048.115 Washer, Flat 3/8 (Stroke Indicator Only) 4
901.048.330 Washer, Flat 3/8 (Stroke Indicator Only) 4
40 560.106.360 Seal (O-Ring) (See item 36) 8
560.106.363 Seal (O-Ring) (See item 36) 8
560.106.364 Seal (O-Ring) (See item 36) 8
560.106.365 Seal (O-Ring) (See item 36) 8
720.060.608 Seal (O-Ring) (See item 36) 8
46 530.033.000 Metal Muffler (for other muffler options see pg. 24) 1
Parts not shown used with Raised Face ANSI Flange Options R and W:
170.035.330 Hex Cap Screw 4
326.052.080 Mounting Foot 2
545.007.330 Hex Nut 4
900.006.330 Lock Washer 4
901.022.330 Flat Washer 8
Parts not shown used with Raised Face ANSI Flange Option R ONLY:
334.115.110 2" ANSI 150# Raised Face Flange
and Threaded Pipe Connection 2
538.024.110 2" NPT Pipe Nipple x 2-1/2" Long 2
Item Part Number Description Qty
1 031.140.000 Air Valve Assembly w/Integral muffler
(Cast Iron Centers Only) 1
031.141.000 Air Valve Assembly (Cast Iron Centers Only) 1
031.146.000 Air Valve Assembly w/Integral muffler
(Stroke Indicator Only) 1
031.147.000 Air Valve Assembly (Stroke Indicator Only) 1
031.173.000 Air Valve Assembly w/Integral muffler 1
031.173.001 Air Valve Assembly (with Stainless Steel Hardware) 1
031.183.000 Air Valve Assembly 1
031.179.000 Air Valve Assembly
(Cast Iron or Stainless Steel Centers Only) 1
2 050.017.354 Ball, Check 4
050.017.360 Ball, Check 4
050.017.360W Ball, Check 4
050.017.364 Ball, Check 4
050.017.364W Ball, Check 4
050.017.365 Ball, Check 4
050.017.365W Ball, Check 4
050.018.600 Ball, Check 4
3 070.006.170 Bushing 2
4 095.110.000 Pilot Valve Assembly 1
095.095.110 Pilot Valve Assembly (Stainless Steel Centers Only) 1
095.110.558 Pilot Valve Assembly (Cast Iron Centers Only) 1
5 114.024.157 Intermediate Bracket 1
114.024.010 Intermediate Bracket 1
114.024.110 Intermediate Bracket (Stainless Steel Centers Only) 1
6 132.035.360 Bumper, Diaphragm 2
7 135.034.506 Bushing, Plunger 2
8 165.116.157 Cap, Air Inlet Assembly 1
165.116.010 Cap, Air Inlet Assembly 1
165.116.110 Cap, Air Inlet Assembly (Stainless Steel Centers Only) 1
9 170.052.115 Capscrew, Hex Hd 3/8-16 X 2.25 16
170.052.330 Capscrew, Hex Hd 3/8-16 X 2.25 16
10 170.060.115 Capscrew, Hex Hd 7/16-14 X 2.00 16
170.060.330 Capscrew, Hex Hd 7/16-14 X 2.00 16
11 170.069.115 Capscrew, Hex Hd 5/16-18 X 1.75 4
170.069.330 Capscrew, Hex Hd 5/16-18 X 1.75 4
12 171.053.115 Capscrew, Soc Hd 3/8-16 X 2.50 4
(Stroke Indicator Only)
171.053.330 Capscrew, Soc Hd 3/8-16 X 2.50 4
(Stroke Indicator Only)
170.006.115 Capscrew, Hex HD 3/8-16 X 1.00 4
170.006.330 Capscrew, Hex HD 3/8-16 X 1.00 4
13 171.059.115 Capscrew, Soc Hd 7/16-14 X 1.25 8
171.059.330 Capscrew, Soc Hd 7/16-14 X 1.25 8
171.011.115 Capscrew, Soc Hd 1/2-13 x 1.00
(Stainless Steel Centers Only) 8
14 196.167.156/157 Chamber, Outer 2
196.167.010 Chamber, Outer 2
196.167.110 Chamber, Outer 2
15 196.168.157 Chamber, Inner 2
196.168.010 Chamber, Inner 2
196.168.110 Chamber, Inner (Stainless Steel Centers Only) 2
16 286.020.604 Diaphragm, Overlay 2
17 286.118.000 Diaphragm, One.Piece Bonded 2
18 286.007.354 Diaphragm 2
286.007.360 Diaphragm 2
286.007.363 Diaphragm 2
286.007.364 Diaphragm 2
286.007.365 Diaphragm 2
19 360.093.360 Gasket, Air Valve 1
20 360.114.360 Gasket, Pilot Valve 1
21 360.104.379 Gasket, Air Inlet 1
22 360.105.360 Gasket, Inner Chamber 2
23 518.145.156 Manifold, Suction 1
518.145.156E Manifold, Suction 2" BSP Tapered 1
518.145.156W Welded Raised Face 150#
2" ANSI Flanged Manifold 1
518.145.010 Manifold, Suction 1
518.145.010E Manifold, Suction 2" BSP Tapered 1
518.145.110 Manifold, Suction 1
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
MODEL SPECIFIC
3: EXP
VIEW
