Composite repair parts list, Atex compliant – SANDPIPER S1F Metallic User Manual
Page 12
s1fmdl1sm-rev0614
sandpiperpump
.
com
9
• Model S1F Metallic
Item
Part Number
Description Qty
1
031.179.000
Air Valve Assembly
(Cast Iron Centers Only)
1
031.146.000
Air Valve Assembly
(Stroke Indicator)
1
031.147.000
Air Valve Assembly
(Stroke Indicator)
1
031.183.000 Air Valve Assembly
1
031.183.001
Air Valve Assembly
(W/Stainless Steel Hardware)
1
031.173.000
Air Valve Assembly
(W/ Aluminum centers only)
1
031.173.001
Air Valve Assembly
(W/ Stainless Steel Hardware only)
1
031.140.000
Air Valve Assembly w/Integral muffler
(Cast Iron Centers Only)
1
031.141.000
Air Valve Assembly
(Cast Iron Centers Only)
1
2
050.028.354
Ball, Check
4
050.028.356
Ball, Check
4
050.028.360
Ball, Check
4
050.028.365
Ball, Check
4
050.028.600
Ball, Check
4
3
070.012.170
Bushing
2
4
095.110.000
Pilot Valve Assembly
1
095.110.558
Pilot Valve Assembly
1
(Cast Iron Centers Only)
5
114.025.157
Intermediate
1
114.025.010
Intermediate
1
6
132.019.360
Bumper
2
7
135.036.506
Bushing
2
8
165.120.157
Cap, Air Inlet Assembly
1
165.120.010
Cap, Air Inlet Assembly
1
9
170.044.115
Capscrew, Hex Hd 5/16-18 X 1.00
16
170.044.330
Capscrew, Hex Hd 5/16-18 X 1.00
16
10
170.045.115
Capscrew, Hex Hd 5/16-18 X 1.25
16
170.045.330
Capscrew, Hex Hd 5/16-18 X 1.25
16
11
170.069.115
Capscrew, Hex Hd 5/16-18 X 1.75
4
170.069.330
Capscrew, Hex Hd 5/16-18 X 1.75
4
12
171.053.115
Capscrew, Hex Soc 3/8-16 X 2.50
4
(Stroke Indicator option only)
171.053.330
Capscrew, Hex Soc 3/8-16 X 2.50
4
(Stroke Indicator option only)
170.006.115
Capscrew, Hex HD 3/8-16 X 1.00
4
170.006.330
Capscrew, Hex HD 3/8-16 X 1.00
4
13
196.173.156/157
Chamber, Outer
2
196.173.010
Chamber, Outer
2
196.173.110
Chamber, Outer
2
14
286.008.354
Diaphragm
2
286.008.356
Diaphragm
2
286.008.360
Diaphragm
2
286.008.363
Diaphragm
2
286.008.364
Diaphragm
2
286.008.365
Diaphragm
2
286.112.000
Diaphragm, One.Piece Bonded
2
15
286.015.604
Diaphragm, Overlay
2
16
360.093.360
Gasket, Air Valve
1
17
360.103.360
Gasket, Pilot Valve
1
18
360.104.379
Gasket, Air Inlet Cap
1
19
518.175.156
Manifold, Suction
1
518.175.156E
Manifold, Suction 1" BSP Tapered
518.175.010
Manifold, Suction
1
518.175.010E
Manifold, Suction 1"
(BSP Tapered)
1
518.175.156W
Welded Raised Face 150#
1" ANSI Flanged Manifold
1
518.175.110
Manifold, Suction
1
518.175.110E
Manifold, Suction 1"
(BSP Tapered)
1
518.175.110W
Welded Raised Face 150#
1" ANSI Flanged Manifold
1
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item
Part Number
Description Qty
20
518.176.156
Manifold, Discharge 1
518.176.156E
Manifold, Discharge 1"
(BSP Tapered)
1
518.176.156W
Welded Raised Face 150#
1" ANSI Flanged Manifold
1
518.176.010
Manifold, Discharge
1
518.176.010E
Manifold, Discharge 1"
(BSP Tapered)
1
518.176.110
Manifold, Discharge
1
518.176.110E
Manifold, Discharge 1"
(BSP Tapered)
1
518.176.110W
Welded Raised Face 150#
1" ANSI Flanged Manifold
1
21
560.001.360
O-Ring
2
22
560.091.360
Seal (Check Valve)
(See item 29) 8
560.091.363
Seal (Check Valve)
(See item 29)
8
560.091.364
Seal (Check Valve)
(See item 29)
8
560.091.365
Seal (Check Valve)
(See item 29)
8
560.091.611
Seal (Check Valve)
(See item 29)
8
23
612.022.330
Plate, Inner Diaphragm
2
612.218.330
Plate, Inner Diaphragm
2
(use with One-Piece Bonded)
24
612.108.157
Plate,
Outer Diaphragm Assembly
2
612.101.082
Plate,
Outer Diaphragm Assembly
2
612.101.110
Plate,
Outer Diaphragm Assembly
2
25
620.022.115
Pin, Actuator
2
26
675.042.115
Ring, Retaining
2
27
685.060.120
Rod, Diaphragm
1
28
720.010.375
Seal, U-Cup
2
29
722.098.550
Seat, Check Ball
4
722.098.080
Seat, Check Ball
(seals required see item 22)
4
722.098.110
Seat, Check Ball
(seals required see item 22)
4
722.098.150
Seat, Check Ball
(seals required see item 22)
4
722.098.600
Seat, Check Ball
4
30
900.004.330
Lock Washer, 5/16
16
900.004.115
Lock Washer, 5/16
16
31
901.038.330
Flat Washer, 5/16 4
901.038.115
Flat Washer, 5/16
4
32
530.033.000
Muffler, Metal
1
Parts not shown used with Raised Face ANSI Flange Options R and W:
170.043.330
Hex Cap Screw
4
326.050.080
Mounting Foot
2
545.003.330
Hex Nut
4
900.001.330
Lock Washer
4
901.002.330
Flat Washer
8
Parts not shown used with Raised Face ANSI Flange Option R ONLY:
334.112.110 1" ANSI 150# Raised Face Flange and
Threaded Pipe Connection
2
538.035.110 1" NPT Pipe Nipple x 1 1/2 Long
2
3: EXP
VIEW
