SANDPIPER ET1 1/2 - M - Manual (Page 9)

Model ET1 1 /
2
-M Type 3 Page 8 et15mdl3sm-rev0614
1 070-006-170 Bearing, Sleeve 2
2 114-002-156 Bracket, Intermediate 1
114-002-010 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-008-000 Bushing, Threaded w/O-Ring 2
5 620-004-110 Plunger, Actuator 2
6 095-073-000 Assembly, Pilot Valve* 1
6-A 095-070-558 Valve Body 1
6-B 755-025-000 Sleeve (without o-ring) 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spool (without o-ring) 1
6-E 560-023-360 O-Ring (Spool) 2
6-F 675-037-080 Retaining Ring 1
7 360-041-425 Gasket, Valve Body 1
8 560-001-360 O-Ring 2
9 095-043-156 Body, Valve 1
095-043-010 Body, Valve 1
10 132-014-358 Bumper, Valve Spool 2
11 165-066-010 Cap, End 2
12 360-048-425 Gasket, Valve Body 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring 6
15 031-066-000 Sleeve & Spool Set 1
16 170-032-115 Capscrew, Hex Head 8
17 170-045-115 Capscrew, Hex Head 4
18 132-002-360 Bumper, Diaphragm 2
19 196-089-156 Chamber, Inner 2
196-089-015 Chamber, Inner 2
20 196-079-600 Chamber, Driver 2
21 560-022-360 O-Ring 2
22 685-007-120 Rod, Diaphragm 1
23 286-005-365 Diaphragm 2
24 170-024-115 Capscrew, Hex Head 8
25 618-003-110 Plug, Pipe 4
26 900-006-115 Washer, Lock 24
27 612-052-157 Plate, Diaphragm 2
612-052-010 Plate, Diaphragm 2
28 612-097-110 Plate, Outer 2
29 807-026-330 Stud 2
30 518-064-110 Manifold, Suction 1
31 518-065-110 Manifold, Discharge 1
32 170-100-115 Capscrew, Hex Head 8
33 050-018-600 Ball, Check Valve 4
34 545-008-110 Nut, Hex 8
35 132-022-360 Bumper, Actuato2
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
* Available only in kit form. Order P/N 031-045-000 which also includes
items 5,7,12 & 35
CONTAINMENT DUTY Type 3
SERVICE AND OPERATING MANUAL
Original Instructions
ET1½ - M
