SANDPIPER ET1 1/2 - M - Manual (Page 10)

et15mdl3sm-rev0614 Model ET1 1 /
2
-M Type 3 Page 9
ITEM TOTAL
NO. PART NO. DESCRIPTION RQD.
36 902-003-000 Stat-O-Seal 2
37 200-037-115 Clamp, Discharge Assy.
(with nuts & bolts) 2
38 200-038-115 Clamp, Suction Assy.
(with nuts & bolts) 2
39 170-089-115 Capscrew, Hex Head 8
41 196-047-110 Chamber, Outer 2
42 530-008-000 Muffler, Exhaust 1
43 312-057-110 Elbow, Suction 2
44 312-058-110 Elbow, Discharge 2
45 361-005-600 Gasket, Sealing (Discharge) 2
46 361-008-600 Gasket, Sealing (Suction) 2
47 170-066-115 Capscrew 8
48 900-003-115 Washer, Lock 8
49 545-007-115 Nut, Hex 16
50 722-040-600 Seat 4
51 115-083-115 Bracket, Foot, Left 2
52 115-084-115 Bracket, Foot, Right 2
53 286-041-604 Diaphragm 2
54 560-077-611 O-Ring 2
55 286-020-604 Diaphragm, Overlay 2
56 618-025-110 Plug, Boss (Includes Item 57) 4
57 560-078-611 O-Ring 4
58 170-022-115 Capscrew 8
59 900-005-115 Washer, Lock 8
60 545-005-337 Nut, Hex Head 8
61 210-008-330 Clip, Safety 1
62 560-023-360 O-Ring 2
Not Shown:
242-001-000 Container 1
031-098-156 Main Air Valve Assembly 1
(Inc. Items 9, 10, 11, 13,
14, 15, 16, 40 and 61)
031-098-010 Main Air Valve Assembly 1
(Inc. Items 9, 10, 11, 13,
14, 15, 16, 40 and 61)
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
