SANDPIPER ET1 1/2 - SM User Manual
Page 9
et15smdl3sm-rev0614
Model ET1 1/2-SM Page 8
ITEM
TOTAL
NO.
PART NUMBER
DESCRIPTION
RQD.
1
095-051-558
Body, Spool Valve
1
2
031-083-000
Sleeve & Spool Set w/Pins
1
3
560-058-360
O-Ring
8
5
675-043-115
Ring, Retaining
2
4
165-078-147
Cap, End
2
6
165-042-157
Cap, Valve Body
1
7 360-056-360
Gasket
1
8
360-057-360
Gasket
1
9
360-058-360
Gasket
1
10
095-074-001
Assembly, Pilot Valve*
1
10-A
095-071-557
Valve Body
1
10-B
755-025-000
Sleeve (without o-ring)
1
10-C
560-033-360
O-Ring (Sleeve)
4
10-D
775-014-000
Spool (without o-ring)
1
10-E
560-023-360
O-Ring (Spool)
4
10-F
675-037-080
Retaining Ring
1
11
170-063-330
Capscrew, Hex Head
1
12
901-035-330
Washer, Flat
7
13
542-001-330
Nut, Square
1
14
170-033-330
Capscrew, Hex Head
4
15
901-005-330
Washer, Flat
4
16
170-043-330
Capscrew, Hex Head
6
170-006-330
Capscrew, Hex Head
6
17
114-007-157
Bracket, lntermediate
1
18
196-042-157
Chamber, Inner
1
19
196-043-157
Chamber, Inner
1
20 560-040-360
O-Ring
2
21 560-001-360
O-Ring
2
22 135-013-162
Bushlng
2
23
675-042-115
Ring, Retainer
2
24
620-007-114
Plunger, Actuator
2
25
196-135-156
Chamber, Driver
2
196-139-156
Chamber, Driver (w/ PTFE overlay)
2
26
070-012-170
Bearing, Sleeve
2
27
720-010-375
Seal, U-Cup
2
29
901-012-180
Washer, Sealing
2
30
807-048-330
Stud
2
31
675-040-360
Ring, Sealing
2
32
685-039-120
Rod, Diaphragm
1
33 132-019-360
Bumper
2
34
612-108-157
Plate, Outer Diaphragm
2
35
612-022-330
Plate, Inner Diaphragm
2
* Available in Kit Form. Order P/N 031-060-000 which also
includes Items 7, 8, 9, 24, & 50.
Repair Parts shown in
bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren Rupp
distributors. The pump owner may prefer to
maintain a limited inventory of these parts
in his own stock to reduce repair downtime
to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
ET1½
-SM
CONTAINMENT DUTY Type 1
SERVICE AND OPERATING MANUAL
Original Instructions
