SANDPIPER ET1 1/2 - SM - Manual (Page 2)

et15smdl3sm-rev0614 Model ET1 1/2-SM Page 1
et15smdl3sm-rev0711
®
1 1 /
2
" (38mm) ASA style flange 0 to 65 gallons per minute
(0 to 246 liters per minute)
1 / 4 " (6mm) 125 psi or 289 ft. of water
(8.8 Kg/cm
2 or 88 meters)
No-lube, no-stall
design.
Meanings of
Abbreviations:
TBB-1-A AL356T6 AL356T6 AL380DC AL380DC AL380DC PS AL380DC 416SS B PS B B B PP 54
TNN-1-A AL356T6 AL356T6 AL356T6 AL380DC AL380DC PS AL380DC 416SS N PS N N N PP 54
TQS-1-A AL356T6 AL356T6 AL380DC AL380DC AL380DC PS AL380DC 416SS N PS S S N PP 54
TCV-1-A AL356T6 AL356T6 AL380DC AL380DC AL380DC PS AL380DC 416SS T PS V V T PP 54
THI-1-A AL356T6 AL356T6 AL380DC AL380DC AL380DC PS AL380DC 416SS T PS E E T PP 54
TGN-1-A AL356T6 AL356T6 AL356T6 AL380DC AL380DC PS AL380DC 416SS T PS N T T PP 54
TGGN-1-A AL356T6 AL356T6 AL380DC AL356T6 AL380DC PS AL380DC 416SS T PS NT T T PP 54
Driver
Chamber
Shipping
Weight
(lbs)
Inner
Chamber
Manifold
& Elbow
Model
ET1½-SM
Type 1
Outer
Chamber
Outer
Driver
Diaphragm
Plate
Inner
Driver
Diaphragm
Plate
Intermediate
Housing
Diaphragm
Rod
Valve
Seat
Driver
Diaphragm
Pumping
Diaphragm Hardware
Ball Valve
Material Air Valve
AL = Aluminum
B = Buna N
DC = Die Cast
E = EPDM *PS = Plated Steel, except wetted area which is 316SS
S = Santoprene
®
SS = Stainless Steel
T = PTFE
V = Viton
®
N = Neoprene
NT = Neoprene with PTFE overlay
PP = Polypropylene - Glass Filled
PS = Plated Steel
ET1½-SM
Type 1
Air-Power ed
Double-Diaphragm Pump
Quality System
ISO9001 Certified
Environmental
Management System
ISO14001 Certified
®Viton is a registered tradename of E.I. du Pont. ®Santoprene is a registered name of Monsanto Corporation. ®Warren Rupp and SANDPIPER are registered tradenames of Warren Rupp, Inc.
® pumps are designed to be powered only by compressed air)
Temperature Limit: 212 ° F - 100 ° C
(SANDPIPER
CONTAINMENT DUTY
SANDPIPER ® Model SANDPIPER ® Model
This pump is part of the Containment Duty Pumps. It is specially fitted with elastomeric driver diaphragms, aluminum spill containment chambers,
and elastomeric or PTFE pumping diaphragms. The liquid-filled containment chambers provide an additional spill containment barrier, should a pumping
diaphragm fail. The Containment Duty design gives the pump user advanced warning of diaphragm failure, before pumpage can damage the air valve,
or be released into the work environment. A “sight tube” style of visual leak detection is standard on this pump, displaying an obvious color change if a leak
occures in the pumping diaphragm. Electronic leak detection is optional with this model.
The Containment Duty Pumps offers many different levels of materials and spill monitoring devices designed to fit a variety of applications and budgets.
SANDPIPER ® Containment Duty Pumps: Sealless Safety
SPET1½SM-REV0106
