Rhino Shelter SHED-12W X 12L X 8H - Manual (Page 2)

Assembly Instructions Shed House Style 12 x 12 x 8
4 EUL-2002 End Upright w/Foot A & B
8 BTSC-2006 Bent Tube Side Crest
4 TC-2000 Top Crest Tube
4 CSU-2001 Center Straight Uprights
2 CW-2005 Corner Wind Brace
10 SCR-2004 Swedged Cross Rails M/F
5 ECR-2003 End Cross Rails F/F
8 TB-3004 Turnbuckles
20 CBN-3005-3 Carriage Bolts – 3 1/4”
10 CBN-3005-2 Carriage Bolts – 2 1/8”
30 CBN-3005-N 3/8” Nuts
30 CBN-3005-W Washers – 3/8” Curved
2 R-3003 3/16” Rope
4 BC-36 Bungee Cord Hold Ups
4 DBA-3000 Earth Cable Anchors
4 UB-3002 U Bolts with Nuts
1 DR-3001 36” Drive Rod
4 EP-1000 1-5/8” Plastic End Plugs
10 EP-1001 1” Plastic End Plugs
P
u
a
Swedged
Cross Rail M/F
Swedged
Cross Rail F/F
Bent Tube
Side Crest
Top Crest Tube
End Upright
w/Foot A
End Upright
w/Foot B
Center Side
Upright
Wind Brace
Bent Tube
Side Crest
Bent Tube
Side Crest
Bent Tube
Side Crest
Wind Brace
End Upright
w/Foot A
Swedged
Cross Rail M/F
Swedged
Cross Rail M/F
Swedged
Cross Rail M/F
Swedged
Cross Rail F/F
Swedged
Cross Rail F/F
Swedged
Cross Rail F/F
Top Crest Tube
Top Crest Tube
Top Crest Tube
Swedged
Cross Rail M/F
Swedged
Cross Rail M/F
Swedged
Cross Rail M/F
End Upright
w/Foot B
Center Side
Upright
Swedged
Cross Rail M/F
Swedged
Cross Rail M/F
SITE PREPARATION
Select a level or as close to level as practical location for
your Rhino Shelter unit. The unit should be placed on a
base of materials suitable for the storage load to be
protected. The unit should not be located under trees,
which will shed hard fruit such as apples, walnuts, or
heavy pine cones. The cover of your unit will protect
against normally leaves and light debris, however large
