URAGANO
MACHINE
URAGANO 2000 URAGANO 3000 URAGANO 4000
Motore, cilindri (n) JD4045 HF275, 4 in line JD6068 HF 285, 6 in line JD6068 HF 285, 6 in line
Engine power HP (kW) 140 (103) 170 (127) 170 (127)
Fuel tank 150 l 225 l 225 l
Traction 4 hydrostatic Poclain MS11 4 hydrostatic Poclain MS11 4 hydrostatic Poclain MS11
Speeds 2 + RM 2 + RM 2 + RM
Max working speed 18 km/h 20 km/h 20 km/h
Max transport speed 36 km/h 40 km/h 40 km/h
Hydraulic differential SL - / LX ● SL - / LX ● SL - / LX ●
Parking brakes Hydr. on rear wheels Hydr. on rear wheels Hydr. on rear wheels
Gear pump for steering 33 l/min 33 l/min 33 l/min
Gear pump for spraying pumps 22 l/min 22 l/min 22 l/min
Gear pump for all services 11 l/min 11 l/min 11 l/min
Minimum boom height 1060 mm 1060 mm 1060 mm
Maximum boom height 3900 mm 3900 mm 3900 mm
Minimum track width 1700 mm 1700 mm 1700 mm
Maximum track width 3050 mm 3050 mm 3050 mm
Length (total) 7600 mm 7600 mm 7600 mm
Width (transport mode) <2550 mm <2550 mm <2550 mm
Height (transport mode) 4000 mm 4000 mm 4000 mm
Weight (empty) 7000 kg* 8000 kg* 8200 kg*
540/65 R24 wheels o o o
420/70 R30 wheels - o o
320/90 R32 wheels - o o
270/95 R36 wheels - ● ●
300/85 R42 wheels o o o
TECHNICAL SPECIFICATIONS
The machine is available in two versions: SL and LX. The second one offers the traction hydraulic differen-
tial, the electronic weighing system for real time tank level also while the machine is tilted and a wide range
of fittings for electronic accessories.
- Not available o Available on demand ● Standard features
*The weight is intended for machine featured equipped with 21 m boom and air sleeve; weight can vary depending on optional options installed and boom model.
