Pearl User Manual
Introduction 12
2.3 Technical Data
2.3.1 Performance
Image Update Rate:
30 Hz (standard); 7.5 Hz (export series)
A/D Resolution:
16 bit
Detector:
Uncooled Focal Plane Array Options - 320x240 (37.5 µm pitch)
Sensitivity/NETD:
0.108 °F @ 86 °F (0.06 °C @ 30 °C)
2.3.2 Environmental
Operating Temperature:
32 to 122 °F (0 °C to 50 °C) (at housing)
Storage Temperature:
-4 to 158 °F (-20 °C to 70 °C)
Relative Humidity:
Non condensing conditions
Weight (No Lens):
440 grams (OEM Camera)
205 grams (Camera Core)
Operating Position:
Any operating position
2.3.3 Interface
OEM Camera
Camera Core
Analog
Output:
TV Output (NTSC)
Coaxial (BNC)
TV Output (NTSC) 4
POS FEMALE MINI
CLAMP MATING
CONNECTOR –
3M PN 37304
Digital
Output:
NA
NA
Power &
Analog
Video
Out:
4 POS MINI CLAMP
PANEL MOUNT
RECEPTACLE -
3M PN 37304
4 POS 3M MINI
CLAMP PLUG -
3M PN 37104
RS232:
3 POS MINI CLAMP
PANEL MOUNT
RECEPTACLE -
3M PN 37303
3 POS MINI CLAMP
RECEPTACLE -
3M PN 37303
2.3.4 Electrical
Power Supply:
9 - 20 Volt DC
Power Consumption:
2.5W Typical, 5W Max
