128-6691

3 of 16

INSTINSTINSTINSTINST

ALLALLALLALLALL

AAAAA

TTTTT

ION INSTRUCION INSTRUCION INSTRUCION INSTRUCION INSTRUC

TTTTT

IONSIONSIONSIONSIONS

8:30AM - 7PM

9AM - 5PM

CENTRAL

EASTERN

6:30AM - 5PM

7AM - 3PM

MOUNTAIN

5:30AM - 4PM
6AM - 2PM

PACIFIC

MON. - FRI.
SATURDAY

DAY

TTOLL-FREE INST

OLL-FREE INST

OLL-FREE INSTALL

ALL

ALLA

TTION ASSIST

ION ASSIST

ION ASSISTA

ANCE

NCE

The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you
do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days
and hours shown (U.S.A. and Canada only).

7:30AM - 6PM

8AM - 4PM

FASTEN THIS END TO SCREW
STUD ON REAR OF CHASSIS

NUT (5MM)

FASTEN THIS END TO SECURE PART OF DASH-
BOARD. DRILL HOLE IF NECESSARY.

SCREW
(5MM)

DETACHABLE
FRONT PANEL

EXISTING DASH OPENING
FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE
NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF
MOUNTING SLEEVE AS A TEMPLATE & CUT OPENING

UNIVERSAL INSTALLATION USING MOUNTING SLEEVE

NUT (5MM)

REMOVE THE PLASTIC FRAME FROM THE FRONT OF THE
CHASSIS BY CAREFULLY UN-SNAPPING IT.

TYPICAL INSTALLATION

ISO INSTALLATION

20° MAX.

FRONT PANEL

CAUTION:

FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS
MUST BE MOUNTED WITHIN 20° OF HORIZONTAL. MAKE
SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.

SIDE VIEW

CHASSIS

UN-SNAP AT 2 PLACES
EACH ON TOP AND BOTTOM

MAXIMUM

SCREW SIZE

M5 x 6

MAXIMUM

SCREW SIZE

M5 x 6

PERFORATED STRAP

RADIO

SCREW STUD

MOUNTING SLEEVE

PLASTIC FRAME

FACTORY MOUNTING
BRACKETS

REMOVAL TOOLS

BEND BOTTOM
TABS DOWNWARD

BEND TOP
TABS UPWARD
