VANTAGE ® 400
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
* To Top of enclosure, add 10.68”(271.3mm) to top of exhaust pipe. Add 6.67”(169.4mm) to top of Lift Bail.
2. Reduced to less than 32V in the CC-stick Mode when VRD (VOLTAGE REDUCTION DEVICE) is on.
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - VANTAGE 400 (K2410-1) (K2410-2)
Make/Model Description Speed (RPM) Displacement Starting Capacities
PERKINS cu. in. (ltrs.) System
(K2410-1) 4 cylinder 135.6(2.2) 12VDC Battery & Fuel: 15 gal.
404C-22 32.7 HP High Idle 1880 starter (57 L)
1800 RPM Bore x Stroke inch (mm) (Group 34; 650 Oil: 8.45Qts. (8L)
naturally aspirated Full Load 1800 cold crank amps)
(K2410-2) water cooled 3.43 X 3.64 65 Amp Alternator Radiator Coolant:
404D-22 Diesel Engine Low Idle 1400 (87.1 x 92.5mm) W / Built in Regulator 8.0 Qts. (7.6L)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
35.94* in. 25.30 in 60.00 in.
913 mm 643 mm 1524 mm
LUBRICATION EMISSIONS FUEL SYSTEM GOVERNOR
Full Pressure (K2410-1) EPA Tier II Mechanical Fuel Pump, Auto air bleed system Mechanical
with Full Flow Filter (K2410-2) EPA Tier 4 interim Electric shutoff solenoid, Indirect fuel injector.
Compliant
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Shutdown on low oil
Single Element Automatic Idler Top outlet can be rotated. pressure & high engine
Made from long life, aluminized steel. coolant temperature
ENGINE WARRANTY: 2 years / 2000 hours, all non-electric components, 3 years major non-electric compo-
nents . See Perkins warranty for details.
Welding Process
DC Constant Current
DC Pipe Current
Touch-Start™TIG
DC Constant Voltage
Output Range
30 TO 500 AMPS
40 TO 300 AMPS
20 TO 250 AMPS
14 TO 36 VOLTS
Max. Weld OCV
@Rated Load RPM
60 Volts
2
Welding Output
Current/Voltage/Duty Cycle
400A / 36V / 100%
450A / 32V / 100%
300A / 32V / 100%
250A / 30V / 100%
400A / 36V / 100%
450A / 32V / 100%
Auxiliary Power 1
12,000 Watts Peak, / 11,000 Watts Continuous, 60 Hz 120/240 Volts Single Phase
19,000 Watts Peak, / 17,000 Watts Continuous, 60 Hz, 240 Volts 3-Phase
PHYSICAL DIMENSIONS
ENGINE
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER OTHER CIRCUIT BREAKERS
(2) 120VAC GFCI Duplex (5-20R) Two 20AMP for Two Duplex Receptacle 10AMP for Battery Charging Circuit
(1) 120/240VAC Dual Voltage (1) 50AMP for Dual Voltage and for 10AMP for 42V Wire Feeder Power
Full KVA (14-50R) 3-Phase (3-pole)
(1) 240VAC 3-Phase (15-50R)
MACHINE SPECIFICATIONS
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
1230 lbs. (559kg.)
