RANGER 305G
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - RANGER 305G (K1726-4, K1726-5)
Make/Model Description Speed (RPM) Displacement Starting Capacities
cu. in. (cu. cm.) System
2 cylinder High Idle 3700 41(674) 12VDC Battery & Fuel: 12 gal.
Starter 45.4 L
(K1726 -4,-5) 23 HP @ Bore x Stroke inch (mm) (Group 58; 435 Oil: 2.0 Qts
Kohler CH23S 3600 RPM Full Load 3500 cold crank amps) 1.9 L
Gasoline 3.15 x 2.64 (80 x 67) Battery Charger
Engine
Low Idle 2400
INPUT - GASOLINE ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
30.00** in. 21.50 in 42.25 in.
762.0 mm 546.0 mm 1073.0 mm
LUBRICATION VALVE LIFTERS FUEL SYSTEM GOVERNOR
Full Pressure Hydraulic Mechanical Fuel Pump Mechanical Governor
with Full Flow Filter Additional electric fuel lift pump
5% Regulation on K1726-5.
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Top outlet Shutdown on low oil
Dual Element Automatic Idler can be rotated. Made from pressure.
long life, aluminized steel.
ENGINE WARRANTY: 2 year unlimited hours (See engine manufacturer warranty for details.)Kohler
Welding Output Volts at Rated Amps Duty Cycle Max. OCV @ 3700 RPM
CC STICK DC Output 29 Volts @ 305 Amps 100%
CC STICK Output Range 20 to 305 Amps -------
PIPE DC Output 29 Volts @ 300 Amps 100%
PIPE Output Range 40 to 300 Amps ------- 60 Volts
CC TIG DC Output 30 Volts @ 250 Amps 100%
TIG Output Range 20 to 250 Amps -------
CV WIRE DC Output 29 Volts @ 300 Amps 100%
CV WIRE Output Range 14 to 29 volts -------
Auxiliary Power 1
10,500 Watts Peak, 9500 Watts Continuous, 60 Hz
120/240 Volts
PHYSICAL DIMENSIONS
ENGINE COMPONENTS
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
510 lbs. (231kg.)
