CONNECTION DIAGRAMS

(continued)

HOOK-UP KITS –

The hook-up kits contain the necessary hoses to connect between your gas
regulator and power source. The hook-up kits are required for proper con-
nection and are ordered separately.

Quantity

KP505 For PTA-9F, PTA-17F, PTA-26F

Part No.

(Industry Ref.)

Description

1

1

S19558-1

(40V77)

S19558-2

–––

Gas hose, 12-1/2’ (3.8mm)

Gas hose, 18” (457mm)
(from solenoid valve to power cable adapter)

Order correct power cable adapter.

Quantity

KP506 For PTA-17V, PTA-26V

Part No.

Description

1

S19558-1

Gas hose, 12-1/2’ (3.8mm) with 5/8-18 right
hand male fittings

Order necessary power cable adapter for 1 piece power cable.
