Connection diagram – Lincoln Electric IM690 POWER WAVE 455R User Manual
Page 39
F-4
CONNECTION DIAGRAM
F-4
POWER WAVE 455/R
Hard Automation, Electrode Positive, STT
Configuration
-
+
WORK
SENSE
LEAD
K940
WATERCOO LED
TORCH
ELECTRODE LEAD
CONTRO L CABLE K1795
WATER CO OLER
POWER
CO NNECT ION
SHIELDING G AS
TO SHIELDING GAS
DEVICENET CABLE
TO PLC/CO NTROLLER
DEVICENET CABLE
TO PLC/CONTROLLER
ELECTRODE LEAD
CONTROL CABLE K1795
WATER COOLER
POWER CONNECTION
WATER
LINES
